Startup Manual 1

Packing List

Before installation, make sure that you have

received the following:

•

ADAM-3624 Product

• ADAM-3624 Startup Manual

If anything is missing or damaged, contact your

distributor or sales representative immediately.

Specications

System Functions

• Analog Output Channels: 4 differential

• Output Type: Voltage, Current

• Resolution 16-bit

• Accuracy ± 0.3% of FSR (Volt

age) at 25°C

± 0.3 % of FSR

(Current) at 25°C

• Power Consumption 1w

• Operation Temp. -40 ~ 70°C

• Warranty 2 years

Notes

For more information on this and other Advantech

products, please visit our websites at:

http://www.advantech.com

For technical support and service:

http://www.advantech.com/support/

This startup manual is for ADAM-3624

Part No: 2003A62400 1st Edition

May 2016

STARTUP MANUAL

ADAM-3624

4-ch Analog Output Module

Application Wiring

Overview

As an ADAM-3600 Extension I/O, the ADAM-

3624 is a 16-bit, 4-channel analog output module.

As a voltage output type, the load can be 2KΩ.

While current output type, the load could be

from 0 to 500. This module is extremely cost-Ω

effective solution for industrial measurement and

monitoring applications.
