User Instructions

ON-X

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building,

and electrical damages, injuries to any persons, and direct or

indirect economic loss associated with the use or reliance of

any information contained within this document, and/or as a

result of the improper, unsafe, unsucient and negligent as-

sembly, installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 3

• Multi-Colors

• 3 Operating Modes - Sound Active, Show Mode, and DMX Control

• 6 DMX Channel Modes (2 Channel Mode, 9 Channel Mode,

11 Channel Mode, 12 Channel Mode, 16 Channel Mode, & 18

Channel Mode)

• Stand Alone or Master-Slave Setup

• Internal Microphone

• Digital Display for Address and Function Setting

• Power Cord Daisy Chain (See page 20)

• UC IR Compatible (Not Included)

ON-X Features

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact ADJ Products, LLC.

ADJ Products, LLC will not accept any liability for any resulting dam-

ages caused by the non-observance of this manual or any unauthor-

ized modication to this unit.

ON-X Handling Precautions

ON-X Warranty Registration

The ON-X carries a 2 year (730 days) limited warranty. Please fill out

the enclosed warranty card to validate your purchase and warranty.

You may also register your product online at www. americandj.com.

All returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) number.

If the unit is under warranty you must provide a copy of your proof of

purchase invoice. Please contact ADJ Products, LLC customer sup-

port for a R.A. number.

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

ON-X General Instructions

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 2

ON-X General Information

Unpacking: Thank you for purchasing the ON-X by ADJ Products,

LLC. Every ON-X has been thoroughly tested and has been shipped

in perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your xture for any damage and be

sure all equipment necessary to operate the unit has arrived intact. In

the event damage has been found or parts are missing, please contact

our toll free customer support number for further instructions. Please

do not return this unit to your dealer without contacting customer sup-

port rst.

Introduction: The ADJ ON-X creates exciting lighting effects with

it’s 8 quick sweeping beams and it’s dual 4-zone LEDs. The ON-X can

operate as a stand alone fixture or in a Master/Slave configuration. The

ON-X has three operating modes; sound active mode, show mode,

and DMX control. This fixture is suitable for theaters, studios, retail

stores, and other similar locations. For best results use fog or special

effects smoke to enhance the beams projections.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.adj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!

Product specificaties

Merk:	Adj
Categorie:	Effect machine
Model:	ON-X
Kleur van het product:	Zwart
Ingebouwd display:	Ja
Gewicht:	2500 g
Breedte:	151 mm
Diepte:	283 mm
Hoogte:	110 mm
Snoerlengte:	1.5 m
Aantal lampen:	8 lampen
Soort lamp:	LED
Vermogen lamp:	3 W
Stroombron:	AC
Ingangsspanning:	100 - 240 V
Aantal:	1
Pulse function:	Ja
Levensduur lamp:	50000 uur
Kleur licht:	Blue, Green, Red, White
Frequentie:	50 - 60 Hz
Stralingshoek:	4 °
Stroomverbruik (typisch):	39 W
Type product:	Disco-spotlight
Type beeldscherm:	LED
Verlichtingsmodi:	DMX, Sound activated
Lichtregelingsprotocollen:	DMX
Dimbereik:	0 - 100 procent
Baldiameter:	- "
Aantal DMX-kanalen:	6 kanalen
