PROGRAMMING GUIDE

Part No. : MUL-53221-07

PROGRAMMING

GUIDE

for

BARCODE

SCANNERS

The guide can be used as keyboard

emulation, RS- 232C serial interface, and

USB 1.1 interface and wand emulation.

IMPORTANT NOTICE

This is a general guide for varies scanners, and

not all functions will perform in every scanners.

Other than specified in this guide, for any special

functions or specications, please contact your

dealer for details.

Every effort is made to ensure the accuracy of our

product information; however, we accept no

responsibility for errors or omissions including, but

not limited to, the implied warranties of

merchantability and tness for a particular purpose.

We shall not be liable for errors contained herein

or for incidental consequential damages in

connection with the furnishing, performance, or

use of this material.

Specification or version may be subject to change

without notice. The actual specification and version

are based on the product delivered.

TABLE OF CONTENTS

Introduction............................................................1

Default Parameters................................................2

Program Procedure ...............................................5

System Setting ......................................................6

General Configuration

Scanning Mode Selection ......................................9

Inter- Message Delay...........................................10

Inter- Character Delay .........................................11

Message/ Block Mode Selection..........................11

Beeper Tone Selection.........................................12

Interface Configuration

RS-232C Serial Communication Parameters Setting

Handshaking Protocol .................................15

ACK/ NAK Response Time Setting .............16

Baud Rate ...................................................16

Data Bit .......................................................17

Stop Bit........................................................17

Parity Setting...............................................17

Message Terminator....................................18

Keyboard Emulation Parameters Setting.............19

Keyboard Type Selection ............................19

Language Selection ....................................21

Message Terminator....................................22

Function Key Emulation ..............................23

Capital Lock Setting ....................................23

Wand Emulation Parameters Setting...................24

Emulation Data Output Selection ................25

Wand Emulation Narrow/Wide Ratio ...........25

Cursor Pad Work at Numlock......................25

USB Interface Parameters Setting.......................26

Keyboard Type ............................................26

Message Terminator....................................26

The Symbologies

Reading Code Selection ......................................28

Code 39 Parameters Setting ...............................30

Interleaved 2 Of 5 Parameters Setting.................31
