Pagina 1/14
INSTALLATION
1
CONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
Contents
Introduction
Welcome 2 ................................................................................................................
Supplied items 3 .......................................................................................................
Optional extras 3 .....................................................................................................
Installation
Connections 4 ..........................................................................................................
Video link 5 .........................................................................................................
Link connection 5 ..............................................................................................
USB and power connections 6 .......................................................................
Conguration
Performing a ash upgrade.................................................................................7
Restoring a backup rmware image .................................................................7
Resetting.................................................................................................................7
Default settings .....................................................................................................8
Operation
Indicators 9 ...............................................................................................................
Further information
Getting assistance ..............................................................................................10
Open source licenses 11 ........................................................................................
Index
INSTALLATION
2
CONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
Introduction
WELCOME
Thank you for choosing the ADDERLink Portal R100 series a compact ZeroU™
device powered by the latest ARDx™ remote access technology from Adder. It provides
secure, low-latency keyboard, video, mouse and audio connectivity via the Internet or a
local network. Designed for image critical applications, it can also be used as a remote
gateway into an ADDERLink INFINITY matrix or ADDERView KVM switch.
Hardware remote KVM
With DisplayPort video and USB2.0 for keyboard, mouse and other HID devices. Unlike
remote access software it operates independently of the target PC, enabling BIOS
control during boot and securely separating remote users from the host network.
ARDx Viewer
The ADDERLink Portal is powered by ARDx™ technology from Adder and is designed
to be partnered with the ARDx Viewer (download from Adder.com), which provides a ™
seamless user experience and powerful admin tools for managing connections and users.
High quality audio and video
Experience exceptional media streaming with HD 1920x1080 resolution at ultra-smooth
60Hz frame rates, 4:4:4 true color and 16-bit 44.1kHz PCM stereo audio. Fluid motion,
accurate color and clear text reproduction for image critical applications.
Seamless User Experience
Inherently low latency provides precision control as though you are operating the
host PC directly. On a network with suitable capacity, up to eight users can access
concurrently without performance degradation.
Highly Secure
Enterprise grade security ensures your connection is safe. AES-256 encryption and RSA-
2048 authentication offer the highest level of protection, trusted by security agencies and
nancial institutions worldwide.
Network Capability
For critical performance applications, ADDERLink Portal is optimized for use over
a Local Area Network (LAN). Wide Area Network (WAN) connectivity for remote
internet access can be achieved through a rewall port or Virtual Private Network
(VPN).
Simple Installation
The ZeroU dongle form factor requires no rack space. USB power from the host ™
PC means no bulky power supply or spare wall socket is required although an external
supply can be used.
Target any OS
Unlike remote access via software, the ADDERLink Portal can control any PC with a
KVM connection, regardless of the Operating System. Advantageous for installations
where the OS may be considered legacy, or conguration change is prohibited.
Local Area
Network
or Internet
Multiple remote
users (up to 8
concurrently)
Single host computer
(or multiple hosts,
if using an optional
KVM switch)
Technical Specications can be
found on the product page of the
website and the data sheet.
