Outdoor Dome

Hardware Manual

A71, A76, A77

Ver. 2024/05/02

www.acti.com
Hardware Manual

2
Table of Contents
Precautions  4
Safety Instructions .......................................................................... 6
Introduction  7
List of Models ................................................................................. 7
Package Contents ........................................................................... 8
Physical Description ........................................................................ 9
Mounting Options ........................................................................ 11
Installation Procedures  12
Step 1: Prepare for Installation..................................................... 12
Step 2: Open the Dome Cover ...................................................... 12
Step 3: Insert the Memory Card .................................................... 13
Step 4: Route the Cables............................................................... 14
Step 5: Mount the Camera ........................................................... 15
Step 6: Connect and Manage the Cables ...................................... 16
Using the Cable Gland ................................................................. 16
Step 7: Connect to Network ......................................................... 19
Step 8: Access the Camera Live View ............................................ 19
Step 9: Adjust the Viewing Angle and Orientation ...................... 19
Step 10: Close the Dome Cover .................................................... 20
Other Cable Connections  21
How to Connect a Power Adapter (Optional) .............................. 21
How to Connect DI/DO Device (Optional) .................................... 22
How to Connect Audio Input /Output Device (Optional) ............. 24
Other Adjustments and Accessories  25
How to Install / Remove the Memory Card .................................. 25
