ZOTAC ZBOX BI329 Handleiding

ZOTAC Desktop ZBOX BI329

Bekijk gratis de handleiding van ZOTAC ZBOX BI329 (21 pagina’s), behorend tot de categorie Desktop. Deze gids werd als nuttig beoordeeld door 17 mensen en kreeg gemiddeld 4.8 sterren uit 9 reviews. Heb je een vraag over ZOTAC ZBOX BI329 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/21

291-MB385-01S6F

ZOTAC ZBOX

User’s Manual

No part of this manual, including the products and software described in it, may

be reproduced, transmitted, transcribed, stored in a retrieval system, or translated

into any language in any form or by any means, except documentation kept by the

purchaser for backup purposes, without the express written permission of ZOTAC.

Products and corporate names mentioned in this manual may not be registered

trademarks or copyrights of their respective companies, and are used for identication

purposes only. All trademarks are the property of their respective owners.

Every effort has been made to ensure that the contents of this manual are correct and

up to date. However, the manufacturer makes no guarantee regarding the accuracy of

its contents, and reserves the right to make changes without prior notice.

CAUTION:

Risk of explosion if the battery is replaced with an incorrect type. Batteries should be

recycled where possible. Disposal of used batteries must be in accordance with local

environmental regulations.

ZOTAC ZBOX

Table of Contents

Product specications ----------------------------------------------------------------------------------------3

Safety information ---------------------------------------------------------------------------------------------- 4

Setting up your system 4 -------------------------------------------------------------------------------------

Care during use 4 ----------------------------------------------------------------------------------------------

Welcome -----------------------------------------------------------------------------------------------------------5

Package contents 5 -------------------------------------------------------------------------------------------

Getting to know your ZOTAC ZBOX ----------------------------------------------------------------------6

Front view 6 -----------------------------------------------------------------------------------------------------

Rear view 7 ------------------------------------------------------------------------------------------------------

Installing hardware inside the ZOTAC ZBOX ----------------------------------------------------------8

Installing a memory module 9 -------------------------------------------------------------------------------

Removing a memory module 10 -----------------------------------------------------------------------------

Installing a hard disk drive --------------------------------------------------------------------------------11

Setting up your ZOTAC ZBOX ------------------------------------------------------------------------------ 13

Positioning the ZOTAC ZBOX ------------------------------------------------------------------------------15

Installing the stand 15 ------------------------------------------------------------------------------------------

Installing drivers and software -----------------------------------------------------------------------------16

Installing an operating system 16 ----------------------------------------------------------------------------

Installing system drivers 16 -----------------------------------------------------------------------------------

Using your ZOTAC ZBOX -------------------------------------------------------------------------------------17

Conguring a wireless connection ----------------------------------------------------------------------17

Conguring audio output -----------------------------------------------------------------------------------18

Product specificaties

Merk:	ZOTAC
Categorie:	Desktop
Model:	ZBOX BI329
Kleur van het product:	Zwart
Gewicht:	- g
Breedte:	188 mm
Diepte:	188 mm
Hoogte:	44 mm
Gebruikershandleiding:	Ja
Bluetooth:	Ja
Frequentie van processor:	1.1 GHz
Processorfamilie:	Intel® Celeron®
Processormodel:	N4100
Aantal processorkernen:	4
Bluetooth-versie:	4.2
Inclusief besturingssysteem:	Windows 10 Pro
Ethernet LAN:	Ja
Geïntegreerde geheugenkaartlezer:	Ja
Processor lithografie:	14 nm
Inclusief AC-adapter:	Ja
Aantal USB 2.0-poorten:	1
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Microfoon, line-in ingang:	Ja
DVI-poort:	Nee
Hoofdtelefoonuitgangen:	1
Netvoeding:	65 W
Inclusief netsnoer:	Ja
Aansluiting voor netstroomadapter:	Ja
Intern geheugen:	4 GB
Opslagmedia:	SSD
Intern geheugentype:	DDR4-SDRAM
HDMI versie:	2.0a
Aantal DisplayPorts:	1
Wifi-standaard:	Wi-Fi 5 (802.11ac)
Ethernet LAN, data-overdrachtsnelheden:	10,100,1000 Mbit/s
Bekabelingstechnologie:	10/100/1000Base-T(X)
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Processor socket:	BGA 1090
Systeembus:	- GT/s
Processor aantal threads:	4
PCI Express slots versie:	2.0
Processor operating modes:	64-bit
Processor cache:	4 MB
Tjunction:	105 °C
PCI Express configuraties:	1x2, 1x2+2x1, 1x4, 2x1, 4x1
Thermal Design Power (TDP):	6 W
Codenaam processor:	Gemini Lake
Maximaal aantal PCI Express-lijnen:	6
ECC ondersteund door processor:	Nee
Processorfabrikant:	Intel
Architectuur besturingssysteem:	64-bit
Maximum intern geheugen:	8 GB
Totale opslagcapaciteit:	64 GB
Soort optische drive:	Nee
Ingebouwde grafische adapter:	Ja
Aparte grafische adapter:	Nee
On-board graphics adapter model:	Intel® UHD Graphics 600
Basisfrequentie ingebouwde grafische adapter:	200 MHz
Graphics on-board -adapter dynamische frequentie (max):	700 MHz
On-board grafische adapter ID:	0x3185
Maximaal geheugen ingebouwde grafische adapter:	8 GB
On-board grafische adapter DirectX-versie:	12.0
Intel® Smart Response Technology:	Nee
Intel® Hyper Threading Technology (Intel® HT Technology):	Nee
Intel® Turbo Boost Technology:	Nee
Intel® Quick Sync Video Technology:	Ja
Intel® AES New Instructions (Intel® AES-NI):	Ja
Enhanced Intel SpeedStep Technology:	Ja
Execute Disable Bit:	Ja
Idle States:	Ja
Thermal Monitoring Technologies:	Ja
CPU configuratie (max):	1
Intel® Enhanced Halt State:	Ja
Intel® VT-x with Extended Page Tables (EPT):	Ja
Ingebouwde opties beschikbaar:	Nee
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Software Guard Extensions (Intel® SGX):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Verpakkingsgrootte processor:	25 x 24 mm
Conflictvrije processor:	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Versie Intel® Identity Protection Technology:	1.00
Versie Intel® Secure Key Technology:	1.00
Versie Intel® Smart Response Technology:	0.00
ARK ID processor:	128983
Intel® Anti-Theft Technology (Intel® AT):	Nee
Maximale turbofrequentie van processor:	2.4 GHz
Discreet grafische adapter model:	Niet beschikbaar
Aantal geïnstalleerde SSD's:	1
SSD capaciteit:	32 GB
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	1
Type behuizing:	SFF
Maximaal intern geheugen ondersteund door processor:	8 GB
Geheugentypen ondersteund door processor:	DDR4-SDRAM, LPDDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor:	2400 MHz
Kloksnelheid geheugen:	2400 MHz
Geheugenlayout:	2 x 4 GB
Geheugenslots:	2x SO-DIMM
SSD interfaces:	SATA III
Totale capaciteit SSD's:	64 GB
Aantal displays ondersteund (door on-board grafische adapter):	3
Aantal geïnstalleerde processoren:	1
Inclusief monitor:	Nee
Aantal verwerkingseenheden:	12
On-board grafische adapter burst frequentie:	700 MHz
UART:	Ja
Scenario Design Power (SDP):	4.8 W
Geheugen kanaal:	Dubbelkanaals
Wifi:	Ja
Type product:	Mini PC
