10GBASE-SR SFP+ 850nm 300m

10GBASE- SR Specifications

Form Factor: SFP+

Data Rate: 10G

Tx/Rx Wavelength: 850nm

Compatible with: See Table

Reach: 300m

Cable Type: MMF

Interface Type: SFP+

DDM/DOM: Yes

Connector Type: Duplex-LC

Power Supply: 3.3V

Temperature Range: 0-70°C

Warranty: Lifetime - See Warranty Document

10GBASE- SR Features

• Hot pluggable SFP+ footprint

• Supports 9.995 to 10.5 Gb/s bit rates

• RoHs-6 compliant

• Built-in digital diagnostic function

• Compliant with OEM vendor multi-source agreement

Testi ng

Compatibility Tested: Each transceiver is tested in an origi-

nal host switch for recognition (Loop back test)

Performance Tested: Tested over an optical connection of

the intended distance. Recreated in the lab using a bit fib re

spool method

100% Testing of all Transceiver s: No Batch Testing (1-10%)

Popular Compatibility Options

Vendor Part Code

Wire 10GBASE- - SR WR

Cisco -10G- SFP SR

Cisco -10G- -S SFP SR

Juniper SFPP-10GE- SR

Juniper QFX- -10GE- SFP SR

Juniper - -10GE- EX SFP SR

Mellanox MFM1T02A- SR

Brocade -SFPP- 10G SR

HPe J9150A

H3C - - -MM850-A SFP XG SX

Checkpoint CPAC- -10SR TR

Extreme Nortel

75+ other vendors available

Description

This 10G-SR compatible SFP+ transceiver provides 10GB -SR throughput up to 300m over Multi-Mode F (MMF) ASE ibre

using a wavelength of 850nm via an LC connector. It is guaranteed to be 100% compatible with the OEM host switch,

router or network interface card (NIC). This easy to install, hot swappable transceiver has been programmed, uniquely

serialized and application tested to ensure that it will initialize and perform identically to the OEM Transceiver. Digital

Optical Monitoring (DOM) support is also present to allow access to real-time operating parameters. We stand be-

hind the quality of our products and proudly offer a lifetime warranty.

Product specificaties

Merk:	Wire Technologies
Categorie:	Niet gecategoriseerd
Model:	10GBASE-SR-WR
Kleur van het product:	Zilver
Minimum operationele temperatuur:	0 °C
Maximale temperatuur (in bedrijf):	70 °C
Land van herkomst:	China
Certificering:	CE, FCC, REACH
Duurzaamheidscertificaten:	RoHS
Netwerkstandaard:	IEEE 802.3ae
Merkcompatibiliteit:	MSA Compliant
Golflengte:	850 nm
Mean time between failures (MTBF):	1000000 uur
Soort aansluiting:	SFP+
Maximale overdrachtssnelheid van gegevens:	10312 Mbit/s
Maximaal bereik:	300 m
Stroomverbruik (typisch):	0.6 W
Bedrijfstemperatuur (T-T):	0 - 70 °C
SFP transceiver type:	Vezel-optiek
Single-mode glasvezelkabel (SMF) ondersteund:	Nee
Multi-mode glasvezelkabel (MMF) ondersteund:	Ja
Vezel-optische connector:	LC
SFP-zendernorm:	SR
Duplex systeem:	Volledig
Fiber ethernet cabling technologie:	10GBASE
Digital Diagnostics Monitoring (DDM):	Ja
Tx vermogen (min):	-7.3 dBmW
Tx vermogen (max):	1 dBmW
