Pagina 1/56
EN
Quick guide
PRODUCT DESCRIPTION
1. Control panel
2. Fan
3. Circular heating element
(not visible)
4. Shelf guides
(the level is indicated on the front
of the oven)
5. Door
6. Upper heating element/grill
7. Lamp
8. Identification plate
(do not remove)
9. Lower heating element
(not visible)
1. SELECTION KNOB
For switching the oven on by
selecting a function. Turn to the
position
to switch the oven off.
2. ANALOG CLOCK
3. THERMOSTAT KNOB
Turn to select the desired
temperature.
4. LED THERMOSTAT /
PREHEATING
Switches on during the heating
process. Switches off once the
desired temperature is reached.
5
4
3
2
1
5
4
3
2
1
1
2
3
4
5
8
9
7
6
CONTROL PANEL
2
3
4
1
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
ACCESSORIES
WIRE SHELF DRIP TRAY* BAKING TRAY* SLIDING RUNNERS*
Use to cook food or as a
support for pans, cake tins
and other ovenproof items
of cookware
Use as an oven tray
for cooking meat, sh,
vegetables, focaccia, etc.
or position underneath the
wire shelf to collect cooking
juices.
Use for cooking all bread
and pastry products, but
also for roasts, sh en
papillotte, etc.
To facilitate inserting or
removing accessories.
TURNSPIT*
* Available only on certain models.
The number and the type of accessories may vary depending on which model is
purchased.
Other accessories can be purchased separately from the After-sales Service.
For uniform roasting of large
pieces of meat and poultry.
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
Insert the wire shelf horizontally by sliding it across
the shelf guides, making sure that the side with the
raised edge is facing upwards.
Other accessories, such as the drip tray and the
baking tray, are inserted horizontally in the same way
as the wire shelf.
REMOVING AND REFITTING THE SHELF GUIDES
• To remove the shelf guides, lift the guides up and
then gently pull the lower part out of its seating: the
shelf guides can now be removed.
• To refit the shelf guides, first fit them back into their
upper seating. Keeping them held up, slide them
into the cooking compartment, then lower them into
position in the lower seating.
FITTING THE SLIDING RUNNERS IF PRESENT
Remove the shelf guides from the oven and remove
the protective plastic from the sliding runners.
Fasten the upper clip of the runner to the shelf guide
and slide it along as far as it will go. Lower the other
clip into position. To secure the guide, press the lower
portion of the clip firmly against the shelf guide. Make
sure that the runners can move freely. Repeat these
steps on the other shelf guide on the same level.
Please note: The sliding runners can be tted on any level.
USING THE TURNSPIT IF PRESENT
Push the skewer through the centre of the meat
(bound with string if poultry) and slide the meat onto
the skewer until it is positioned firmly on the fork and
cannot move. Push the second fork onto the skewer
and slide it on until it holds the meat firmly in place.
Tighten the fixing screw to secure it in position. Insert
the end into the recess provided in the oven’s cooking
compartment and rest the rounded part on the
relevant support.
Please note: To collect the cooking juices, position the drip
tray below and add 500 ml of water. To avoid burning
yourself when the skewer is hot, only handle it by the plastic
handle (which must be removed before cooking).
The use of this accessory is allowed only in combination with
the Turbogrill function.
