DAILY REFERENCE

GUIDE

THANK YOU FOR PURCHASING A

WHIRLPOOL PRODUCT

To receive more comprehensive help and

support, please register your product at

www . whirlpool . eu/ register

WWW

You can download the Safety Instructions

and the Use and Care Guide by visiting our

website docs . whirlpool . eu and following the

instructions on the back of this booklet.

Before using the appliance carefully read the Health and Safety guide.

PRODUCT DESCRIPTION

1. Control panel

2. 6th Sense Humidity sensor

3. Fan and circular heating element

(not visible)

4. Shelf guides

(the level is indicated on the front

of the oven)

5. Door

6. Upper heating element/grill

7. Lamp

8. Meat probe insert point

9. Identification plate

(do not remove)

10. Lower heating element

(not visible)

CONTROL PANEL DESCRIPTION

3 4 5 76 8 9

1. ON / OFF

For switching the oven on and off

and for stopping an active function.

2. FUNCTIONS DIRECT ACCESS

For quick access to the functions

and menu.

3. NAVIGATION BUTTON MINUS

For scrolling through a menu and

decreasing the settings or values of

a function.

4. BACK

r returning to the previous screen.

During cooking, allows settings to

be changed.

5. DISPLAY

6. CONFIRM

For confirming a selected function

or a set value.

7. NAVIGATION BUTTON PLUS

For scrolling through a menu and

increasing the settings or values of a

function.

8. OPTIONS / FUNCTIONS DIRECT

ACCESS

For quick access to the functions,

duration, settings and favorites.

9. START

For starting a function using the

specified or basic settings.

ACCESSORIES

WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS*

Use to cook food or as a

support for pans, cake tins

and other ovenproof items of

cookware.

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking juices.

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

To facilitate inserting or

removing accessories.

MEAT PROBE

To measure the core

temperature of food during

cooking.

* Available only on certain models

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across the

shelf guides, making sure that the side with the raised

edge is facing upwards.

Other accessories, such as the drip tray and the baking

tray, are inserted horizontally in the same way as the

wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating: The

shelf guides can now be removed.

• To refit the shelf guides, first fit them back into their

upper seating. Keeping them held up, slide them

into the cooking compartment, then lower them into

position in the lower seating.

FITTING THE SLIDING RUNNERS (IF PRESENT)

Remove the shelf guides from the oven and remove the

protective plastic from the sliding runners.

Fasten the upper clip of the runner to the shelf guide

and slide it along as far as it will go. Lower the other clip

into position.

To secure the guide, press the lower portion of the

clip firmly against the shelf guide. Make sure that the

runners can move freely. Repeat these steps on the

other shelf guide on the same level.

Please note: The sliding runners can be tted on any level.

USING THE MEATPROBE

Insert the food probe deep into

the meat, avoiding bones or fatty

areas. For poultry, insert the probe

lengthways into the centre of the

breast, avoiding hollow areas.

Place the food in the oven and

connect the plug by inserting it into

the connection provided on the

righthand side of the oven’s cooking

compartment.

Product specificaties

Merk:	Whirlpool
Categorie:	Oven
Model:	W6 OM4 4PBS1 P
Apparaatplaatsing:	Ingebouwd
Soort bediening:	Touch
Kleur van het product:	Black, Stainless steel
Deurscharnieren:	Neer
Ingebouwd display:	Ja
Gewicht:	40500 g
Breedte:	595 mm
Diepte:	564 mm
Hoogte:	595 mm
Netbelasting:	3650 W
Snoerlengte:	0.9 m
Energie-efficiëntieklasse:	A+
Gewicht verpakking:	42500 g
Breedte verpakking:	630 mm
Diepte verpakking:	650 mm
Hoogte verpakking:	690 mm
Geïntegreerde klok:	Ja
Soort klok:	Elektronisch
Convectie koken:	Ja
Totale binnen capaciteit (ovens):	73 l
Aantal ovens:	1
Controle positie:	Voorkant
Soort reiniging:	Pyrolytisch
Stroom:	16 A
Energieverbruik (conventioneel):	0.91 kWu
Energieverbruik (geforceerde convectie):	0.7 kWu
Energie-efficiëntie-index (EEI):	81.9
Koken:	Ja
Grootte oven:	Middelmaat
Soort oven:	Elektrische oven
Totaal vermogen van de oven:	- W
Netto capaciteit oven:	73 l
Zelfreinigend:	Ja
