Owner’s Manual

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

PLEASE SCAN THE QR CODE ON

YOUR APPLIANCE IN ORDER TO

REACH MORE INFORMATION

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Control panel

2. Fan

3. Circular heating element

(not visible)

4. Shelf guides

(the level is indicated on the

front of the oven)

5. Door

6. Inlet pipe plug-in nozzle

7. Drain nozzle

8. Upper heating element/grill

9. Lamp

10. Identification plate

(do not remove)

11. Lower heating element

(not visible)

CONTROL PANEL DESCRIPTION

2 3

1. ON / OFF

For switching the oven on and off.

2. HOME

For gaining quick access to the

main menu.

3. FAVORITE

For retrieving up the list of your

favorite functions.

4. DISPLAY

5. TOOLS

To choose from several options

and also change the oven settings

and preferences.

6. REMOTE CONTROL

To enable use of the 6

Sense Live

Whirlpool app.

7. CANCEL

To stop any oven function except

the Clock, Kitchen Timer and

Control Lock.

ACCESSORIES

WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS *

Use to cook food or as a

support for pans, cake tins

and other ovenproof items of

cookware

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking juices.

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

To facilitate inserting or

removing accessories.

STEAM TRAY

INLET PIPE

This makes it easier for steam

to circulate, which helps cook

the food evenly. Place the drip

tray on the level below to

collect the cooking juices.

Connect to the special nozzle

to draw the water to be

loaded into the reservoir. After

use, rinse and dry thoroughly

before storing it in a cool and

dry place.

* Availble only on certain models

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across

the shelf guides, making sure that the side with the

raised edge is facing upwards.

Other accessories, such as the drip tray and the

baking tray, are inserted horizontally in the same way

as the wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating:

The shelf guides can now be removed.

• To refit the shelf guides, first fit them back into

their upper seating. Keeping them held up, slide

them into the cooking compartment, then lower

them into position in the lower seating.

FITTING THE SLIDING RUNNERS (IF PRESENT)

Remove the shelf guides from the oven and remove

the protective plastic from the sliding runners.

Fasten the upper clip of the runner to the shelf guide

and slide it along as far as it will go. Lower the other

clip into position. To secure the guide, press the lower

portion of the clip firmly against the shelf guide.

Make sure that the runners can move freely. Repeat

these steps on the other shelf guide on the same

level.

Please note: The sliding runners can be tted on any level.

Product specificaties

Merk:	Whirlpool
Categorie:	Oven
Model:	W11I OP1 4S2 H
Apparaatplaatsing:	Ingebouwd
Soort bediening:	Touch
Vermogen grill:	2450 W
Kleur van het product:	Grijs
Deurscharnieren:	Neer
Ingebouwd display:	Ja
Gewicht:	40500 g
Breedte:	595 mm
Diepte:	564 mm
Hoogte:	595 mm
Grill:	Ja
Snoerlengte:	0.9 m
Kinderslot:	Ja
Energie-efficiëntieklasse:	A+
Verlichting binnenin:	Ja
Geïntegreerde klok:	Ja
Soort klok:	Elektronisch
Convectie koken:	Ja
Warmhoud functie:	Ja
Soort lamp:	Halogeen
Totale binnen capaciteit (ovens):	73 l
Aantal ovens:	1
Makkelijk schoon te maken:	Ja
Controle positie:	Voorkant
Installatie compartiment breedte:	- mm
Installatie compartiment diepte:	- mm
Installatie compartiment hoogte:	- mm
Soort reiniging:	Hydro
Stroom:	16 A
Energieverbruik (conventioneel):	0.91 kWu
Energieverbruik (geforceerde convectie):	0.7 kWu
Koken:	Ja
Grootte oven:	Middelmaat
Soort oven:	Elektrische oven
Totaal vermogen van de oven:	3650 W
Netto capaciteit oven:	73 l
Zelfreinigend:	Ja
Vingerafdrukbestendig:	Ja
Pizzafunctie:	Ja
Heteluchtgrillen:	Ja
Aantal kookprogramma's:	8
Brood maak mogelijkheid:	Ja
AC-ingangsspanning:	220-240 V
AC-ingangsfrequentie:	50-60 Hz
Energie-efficiëntieschaal:	A+++ tot D
Brood & deeg maken programma's:	Gistend
Oven-ontdooifunctie:	Ja
Diepvriesmodus:	Ja
