1 “ON/OFF” button
2 Programme selector
3 “Start/Pause” button
4 “Spin” button
5 “Intensive rinse” button
6 “Clean+” button /
“Key lock“ button
7 “Start delay” button
8 “FreshCare+”
9 “Temperature” button
DISPLAY INDICATORS
Door locked
FreshCare+ activated
Start delay activated
Key lock activated
Washing phase
Indicates washing phase of the cycle
Failure: Call Service
Refer to Troubleshooting section
Failure: Water lter clogged
Water cannot be drained; water lter
might be blocked
Failure: No water
No or not sucient inlet water.
In the event of any failure, refer to the
“TROUBLESHOOTING” section
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
CONTROL PANEL
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter - behind plinth
7. Plinth (removable)
8. Adjustable feet (4)
1.
2.
7.
3.
4.
5.
6.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover
or water softener. For a liquid detergent it
is recommended to use removable plastic
partition A (supplied) for a proper dosage. If
powder detergent is used, place the partition
into slot B.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch.
Pour in softener or starch solution only up to the “max” mark.
Release button
Press to remove tray for cleaning.
A
B
EN
Quick guide
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
2153
9
4
7
8
6
Max load 8 Kg
Power consumption in o -mode 0.5 W / in left-on mode 8 W
Detergents and additives
Recommended
detergent
Residual
dampness % **
Energy
consumption
kWh
Total water lt
Programme
Temperatures
Max. spin
speed
(rpm)
Max
load
(kg)
Duration
(Minutes)
Prewash
Main
wash
Softener
PowderLiquid
DefaultRange
Mixed40°C - 40°C1000***–8.0
–
–––
White (1)60°C
- 90°C1200***8.0
(90°)
–––
Cotton40°C
- 60°C1200255–8.0
491,1097
Cotton (2)60°C
60°C1200230–8.0
530,9054
40°C1200255–8.0
491,1097
Sport40°C
- 40°C600***–4.0
–
–––
Duvet30°C
- 30°C1000***–3.5
–
–––
Steam Refresh–––***––––––––2.0
Spin & Drain––1200***––––––––8.0
Rinse & Spin––1200***––8.0
–––––
Rapid 30 min30°C
- 30°C800***–4.5
–
–––
Colours 15°15°C15°C1000***–4.5
–
–––
Wool40°C
- 40°C800***–2.0
–
–––
Delicates30°C
- 30°C–***–1.0
–
–––
Synthetics40°C
- 60°C1200175–4.5
350,8055
Dosing required Dosing optional
For all Test Institutes
Long wash cycle for cottons: set wash cycle with a temperature of 40°C. Cotton
Synthetic program along: set wash cycle with a temperature of 40°C.Synthetics
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting
of the programmes, without options.
** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
*** The duration of the programme is shown on the display.
6th Sense - the sensor technology adapts water, energy and programme duration to your
wash load.
1)Test wash cycle according to UAE.S 5010-2 : 2019 regulations:
Set WHITE wash program at a temperature of 60°C for the Standard Cotton 60°C.
2)
Test programmes according to OS 1651/2022: set the wash cycle
“
Cotton
“
with
a temperature of 60°C for Cotton Standard 60°C and the wash cycle
“
Cotton
“
with
temperature of 40°C for Cotton Standard 40°C.
2)Test programmes according to
KWS 1899:2023: set the wash cycle
“
Cotton
“
with a temperature of 60°C for Cotton Standard 60°C and the wash cycle
“
Cotton
“
with
temperature of 40°C for Cotton Standard 40°C.
Cotton Test wash cycles in compliance with regulations 1061/2010-
These are the reference programs for the energy label. Set this wash cycles with a
temperature of 40°C or 60°C. They are the most ecient programmes in terms of energy
and water consumption for washing normally soiled cotton laundry. The actual water
temperature may dier from the declared one.
