Vivotek SD9365-EHL Handleiding

Vivotek Bewakingscamera SD9365-EHL

Bekijk gratis de handleiding van Vivotek SD9365-EHL (356 pagina’s), behorend tot de categorie Bewakingscamera. Deze gids werd als nuttig beoordeeld door 13 mensen en kreeg gemiddeld 4.8 sterren uit 7 reviews. Heb je een vraag over Vivotek SD9365-EHL of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/356

User’s Manual

Speed Dome

Network Camera

2MP • 20x/30x Zoom • 60fps • NEMA 4x • 250m IR

IP66 • Extreme Weatherproof

SD9366-EH/EHL

SD9365-EHL

Rev. 1.2

VIVOTEK

2 - User's Manual

Table of Contents

Read Before Use ..................................................................................................................................... 3

Overview.......................................................................................................................................................4

Revision History ......................................................................................................................................4

Package Contents ...................................................................................................................................5

Symbols and Statements in this Document .............................................................................................5

Physical Description

............................................................................................................................. 6

Hardware Installation ............................................................................................................................. 10

Network Deployment .............................................................................................................................21

Software Installation ..............................................................................................................................24

Ready to Use .........................................................................................................................................25

Accessing the Network Camera .................................................................................................................26

Using Web Browsers ............................................................................................................................. 26

Using RTSP Players ..............................................................................................................................28

Using 3GPP-compatible Mobile Devices ...............................................................................................29

Using VIVOTEK Recording Software ....................................................................................................30

Main Page ..................................................................................................................................................31

Client Settings ............................................................................................................................................37

Conguration ..............................................................................................................................................42

System > General settings ....................................................................................................................43

System > Homepage layout .................................................................................................................44

System > Logs ......................................................................................................................................47

System > Parameters ........................................................................................................................... 48

System > Maintenance .......................................................................................................................... 49

Media > Image ....................................................................................................................................53

Media > Video .......................................................................................................................................64

Media > Audio........................................................................................................................................71

Network > General settings ...................................................................................................................72

Network > Streaming protocols ...........................................................................................................80

Network > DDNS .................................................................................................................................84

Network > SNMP (Simple Network Management Protocol) ..................................................................89

Security > User Account ........................................................................................................................90

Security > HTTPS (Hypertext Transfer Protocol over SSL/TLS) ................................................91

Security > Access List .........................................................................................................................98

PTZ > PTZ settings ............................................................................................................................103

Event > Event settings ........................................................................................................................ 112

Applications > Motion detection...........................................................................................................127

Applications > DI and DO ..................................................................................................................130

Applications > Audio detection ..........................................................................................................131

Applications > VADP (VIVOTEK Application Development Platform) ................................................133

Recording > Recording settings .........................................................................................................136

Product specificaties

Merk:	Vivotek
Categorie:	Bewakingscamera
Model:	SD9365-EHL
Kleur van het product:	Wit
Gewicht:	5700 g
Hoogte:	364.2 mm
Soort:	IP-beveiligingscamera
Internationale veiligheidscode (IP):	IP66
LED-indicatoren:	Ja
Bluetooth:	Nee
Ondersteund audioformaat:	G.711, G.726
Ondersteunde videoformaten:	H.264, H.265, M-JPEG
Stemcodecs:	G.711, G.726
Vormfactor:	Dome
Automatisch scherpstellen:	Ja
Ondersteuning voor plaatsing:	Binnen & buiten
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Ja
Montagewijze:	Plafond/muur
Ondersteunde video-modi:	1080p
Maximum resolutie:	1920 x 1080 Pixels
Videocompressieformaten:	H.264, H.265, M-JPEG
Diameter:	236.45 mm
Type stroombron:	Power over Ethernet (PoE)
Stroomuitvoer (volt):	24
Minimale belichting:	0 Lux
Aantal cameras:	1
Geïntegreerde geheugenkaartlezer:	Ja
Compatibele geheugenkaarten:	SD, SDHC, SDXC
Ingebouwde HDD:	Nee
Nachtvisie:	Ja
LED-type:	IR
Video bewegings-detectie:	Ja
HTTPS-encryptie:	Ja
Audiosysteem:	2-weg
Zoomcapaciteit:	Ja
Brandpuntbereik:	4.7 - 94 mm
Certificering:	CE, FCC Class A, VCCI, C-tick, NEMA 4X, UL
Volledige HD:	Ja
Omvang optische sensor:	1/3 "
Beeldstabilisator:	Ja
Type beeldsensor:	CMOS
Digitale zoom:	128 x
Optische zoom:	20 x
Camera sluitertijd:	1/8 - 1/30000 s
Interface:	RJ-45
Ondersteunde grafische resoluties:	1920 x 1080 (HD 1080)
Ruisonderdrukking:	Ja
Bekabelingstechnologie:	10/100/1000Base-T(X)
Ondersteunde beveiligingsalgoritmen:	HTTPS, SNMP
Aantal gebruikers:	10 gebruiker(s)
Temperatuur bij opslag:	-40 - 55 °C
Maximaal 30 frames per seconde:	60 fps
Ondersteunde netwerkprotocollen:	IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS, NTCIP
Progressive scan:	Ja
Flash memory:	128 MB
Ethernet interface type:	Gigabit Ethernet
Signaal/ruis-verhouding:	53 dB
Quality of Service (QoS):	Ja
Power over Ethernet (PoE):	Ja
IK code:	IK10
PTZ control:	Ja
Pan bereik:	0 - 360 °
Dag/nacht modus:	Ja
Draai-snelheid:	300 °/sec
Pan snelheid:	300 °/sec
Videostreaming:	Ja
Nachtkijker afstand:	150 m
Infrarood (IR)-afsluitingsfilter:	Ja
Achtergrondverlichting compensatie:	Ja
Highlight Compensation (HLC) (compensatie voor sterke belichting):	Ja
Aanpassing van de afbeeldingskwaliteit:	Brightness, Contrast, Saturation, Sharpness
Wide Dynamic Range (WDR):	Ja
Wifi:	Nee
Bedrijfstemperatuur (T-T):	-40 - 55 °C
Bereik kantelhoek:	-110 - 110 °
Privézone maskeren:	Ja
Kijkhoek lens, horizontaal:	55 °
Draaien & spiegelen:	Ja
Tijdsaanduiding-overlay:	Ja
Kijkhoek lens, diagonaal:	63 °
Kijkhoek lens, verticaal:	33 °
Actieve ombevoegde demontage alarm:	Ja
Smart IR:	Ja
3D-geluidsreductie:	Ja
Auto-tracking:	Ja
Tekstoverlay:	Ja
Automatische pan-modus:	Ja
Automatische patrol-modus:	Ja
Iris:	Ja
Verwijderbare IR-filter:	Ja
Audio detectie:	Ja
