www.vitekcctv.com

TRANSCENDENT “GEN IV” SERIES

NDAA COMPLIANT IP CAMERAS WITH

AI POWERED FACIAL DETECTION AND

MORE!

Transcendent Series NDAA Compliant High Definition 4 Megapixel

IP Network Cameras with Gen. IV Advanced Analytics including Face

Detection and Target Counting offer unprecedented performance

and value. These simple, easy to install, attractively styled, IP

Network Cameras transmit over remote viewing via CMS, Web

Browser, and iOS & Android Apps.

Transcendent Gen. IV 4 MegaPixel Advanced A.I.

Fixed Lens Vandal Dome Camera [PRELIMINARY SPECS]

VTD-TND4RFA4

•1/3” 4 MegaPixel Progressive Scan Starlight CMOS Sensor

• Up to 30fps @ 4 MegaPixel (2592×1520)

• Available in 3.6 or 2.8mm Fixed Lens Configurations:

VTD-TND4RFA4 (Ivory w/ 3.6mm), VTD-TND4RFA4-2 (Ivory w/ 2.8mm),

VTD-TND4RFA4B (Charcoal w/ 3.6mm),

VTD-TND4RFA4B-2 (Charcoal w/ 2.8mm)

• Matrix IR (up to 100’ IR Range)

• True Wide Dynamic Range (120dB)

• True Mechanical Day/Night function by ICR

• XD-DNR (3D & 2D-DNR) Noise Reduction

• Gen. IV Advanced Analytics: Regional Entrance / Exit Detection, Line

Crossing, Target Counting [All by Human / Motor Vehicle Classification]

Face Detection, Object Abandoned / Missing, Heat Map, Video Blur,

Video Color Cast Detection, Abnormal Video

• H.265+ / H.265 / H.264+ / H.264 / MJPEG

• 1 Ch. Audio In + Built-in Mic* + Alarm In / Out

• Remote Viewing via CMS, Web Browser, iOS & Android Apps

• ONVIF Compliant

• MicroSD Card Slot for Local Recording (256GB)

• IP67 Weather Resistance + IK10 Impact Rating

•

Optional Junction Box (VT-TJB03A), Wall Mount (VT-TWMT3), Pendant Mount

(VT-TPDM-1 [reqs. VT-TJB03A]) and In-Ceiling Semi Flush Mount (VT-TFMT-S)

Available

[See Additional Mounting Options Below]

• 12VDC & PoE (Power over Ethernet) Operation

• 3-Year Warranty

KEY FEATURES

*Please research local, state and federal laws regarding the implementation of audio surveillance.

GEN. IV ADVANCED ANALYTICS

FACIAL

DETECTION

Security personnel

can find out who

entered / left the

restricted area and

at what time

TARGET

COUNTING

Keep count of

vehicles,

motorbikes,

bicycles and people

in a given area

REGIONAL

ENTRANCE/EXIT

Begin NVR recording

and receive an alert upon

subjects entering /

exiting; ideal for

property monitoring

VT-TJB03A

Optional

Junction box

for Cable

Management

VT-TFMT-S

In-Ceiling

Semi-Flush

Mount

VT-TPDM-1

Pendant Mount

- reqs.

VT-TJB03A

VT-TWMT3

Optional Wall

Mount

VT-TPLMT

Universal Pole

Mount Adapter -

reqs. VT-TJB03A

VT-TCNMT

Universal Corner

Mount Adapter -

reqs. VT-TJB03A

Pair with VITEK Transcendent Series

Network Recorders VT-TNR818PF,

VT-TNR1646PF, and VT-TNR3216PF with

Built-in PoE and Fully Programmable

Intelligent Analytics including Facial

Detection.

4.69” (119mm)

3.44”

(87.4mm)

4.60”

(117mm)
