VITEK

VITEK

VTC-TNB5TH

VT-BB501

Transcendent Series 5 MegaPixel

Bi-Spectrum Long-Range Thermal

WDR IP Motorized Bullet Camera

QUICK START GUIDE

FEATURES - VISIBLE LIGHT

• 1/2.7” 5.0 Megapixel CMOS Image Sensor

• 5MP (2592 × 1944) @30 fps

• 8mm @ F2.0 Fixed Iris Lens (1/30s ~ 1/100000s)

• Field of View - 38°×27.5°(H×V)

• Captures 30 Faces Simultaneously

• Built-In White Light and Loudspeaker

• 120Db True Wide Dynamic Range (WDR)

• XD-DNR (3D & 2D Digital Noise Reduction)

• BLC, HLC, De-Fog

FEATURES - THERMAL LIGHT

• 17um 384×288 Vanadium Oxide Uncooled Focal Plane Detector

• Noise Equivalen Temp. Difference (NETD): <35mK(@25°C, F#=1.0)

• S12.3mm@F1 Thermal Imaging Lens

• 29.7°×22.5°(H × V)

• Minimum Focus Distance: 4’5” (1.34m)

• Temperature Measuring Distance 6’6”~20’ (2~6m)

• Black, White, Pseudo-color

GENERAL FEATURES

• Fully Programmable Gen. III Advanced Analytics: Face Detection, Target Counting,

Intrusion, Region Entrance / Exit, Line Crossing, Scene Change, Video Blur

• H.265/H.264/MJPEG

• Remote Viewing via CMS, Internet Explorer, iOS & Android Apps

• MicroSD Card Slot for Local Recording (256GB)

• Sound and Light Warning

• 1 Ch. Audio In + 1 Ch. Audio Out

• 1 Ch. Alarm Input + 1 Ch. Alarm Output

• ONVIF Compliant

• IP66 Weather Resistance

• 12VDC & PoE (Power over Ethernet) Operation

• Ceiling or Wall Mounting Feasability with Included Mount (Other Accessories Sold

Separately - See Following Page)

• 2-Year Warranty

*Please research local, state and federal laws regarding the implementation of audio surveillance.

PLEASE NOTE:

Complete User Guide, Software, Tools, and Updates are

available online. Scan the QR Code or visit:

http://www.vitekcctv.com/Downloads

PLUS

+

VT-BB501 - Black Body Temperature

Calibration Device (sold separately)
