VITEKCCTV.COM

(888) VITEK-70

VTC-THT5R3/2

Transcendent Series 5 MegaPixel Indoor/Outdoor

4-in-1 Fixed Turret Camera

Image Sensor

Signal System

Effective Pixels

Resolution

Video Output

Lens

Day/Night

Min. IIIumination

IR LEDs

IR Distance

S/N Ratio

WDR

Noise Reduction

White Balance

BLC, LSC, HLC

Control over COAX (COC)

Transmission Distance

Power Input

Power Consumption

(12VDC)

Resistance Rating

Operation Conditions

Weight

Dimensions

1/2.7” 5.0 Megapixel Progressive Scan CMOS Sensor

PAL / NTSC

2560 x 1936

HD-TVI & AHD: 5.0 MegaPixel / CVI: 4.0 MegaPixel /

CVBS: 960H

HD-TVI / AHD / CVI / CVBS (Selectable)

3.6 or 2.8mm - Fixed

True Day/Night by ICR

Color: 0.01 [email protected], AGC ON /

B/W: 0 lux (with IR ON)

1 Matrix

Up to 100’

≥52 dB (AGC Off)

Digital WDR

Digital Noise Reduction (D-DNR)

Auto (AWB)

YES

YES

Up to 1500’ (Depending on cable characteristics &

integrity)

12VDC

IR Off: 100mA / IR On: 350mA

IP67

-4°~122° / 10%~90% Humidity

14.81 oz. / .93 lbs. / 420g

3.77” × 4.25” (95.7 × 108mm)

SPECIFICATIONS

KEY FEATURES

VT-TJB01

Optional

Junction

VT-TJB08

Optional

Junction Box

VT-TWMT-3

Optional Wall

Mount

RECORDERS

Pair with VITEK Transcendent

Series 5-in-1 Digital Video

Recorders Supporting HD-TVI

/ AHD / CVI / IP / 960H

Cameras!

• 1/2.7” 5.0 Megapixel Progressive Scan CMOS Sensor

• NDAA Compliant

• High Definition Analog (HDA): HD-TVI & AHD: 5.0 MegaPixel / CVI: 4.0

MegaPixel / CVBS: 960H Video Output

• 3.6 or 2.8mm Fixed Lens

• Matrix with 100’ IR Range

• Digital Wide Dynamic Range (D-WDR)

• True Mechanical Day/Night function by ICR

• 3D-DNR Noise Reduction

• IP67 Weather Resistance

• Supports Control over COAX (CoC)

• Over 1500’ HD Video Transmission (Depending on cable characteristics

and integrity)

• Optional Junction Boxes (VT-TJB01, VT-TJB08) and Wall Mount

(VT-TWMT-3) Available *See other mounting options below

• Available in Ivory or Charocal Grey (VTC-THT5R3B/2B)

• 12VDC Operation

• 3-Year Warranty

ACCESSORIES

(888) VITEK-70 • WWW.VITEKCCTV.COM

VT-TR4VPK

Video and

Power Balun

Transmitter /

Receiver Pair

for HD-TVI /

AHD / CVI for

Distances Up to

VT-TR4K

Passive Video

Balun Transmitter

/ Receiver Pair for

HD-TVI / AHD /

CVI for Distances

Up to 1440’

VT-TPDMT-A1

Indoor Pendant

Mount - reqs.

VT-TJB08

VT-TPDM-2

Outdoor

Pendant Mount -

reqs. VT-TJB01

VT-TWMT-A1

Optional

Wall Mount

- reqs.

VT-TJB08

VT-TPLMT

Univeral Pole

Mount - reqs.

VT-TWMT-A1

+VT-TJB08

VT-TCNMT

Univeral

Corner Mount

- reqs.

VT-TWMT-A1

+VT-TJB08

4.25”

(108.0mm)

3.77”

(95.7mm)

4.25”

(108.0mm)

3.77”

(95.7mm)
