VITEKCCTV.COM

(888) VITEK-70

VTC-THT2RFE-2

Transcendent Series 2 MegaPixel Indoor/Outdoor

4-in-1 HDA Fixed Lens Turret Camera

SPECIFICATIONS

KEY FEATURES

RECORDERS

• 1/2.9” 2.1 MegaPixel Progressive Scan CMOS image sensor

• High Definition Analog (HDA): HD-TVI / AHD / HD-CVI: 1080p/720p (2.1

MegaPixel) / CVBS: 960H Video Output

• 2.8mm Fixed Iris Lens

• 1 Matrix IR with up to 100’ IR Range

• Digital Wide Dynamic Range (D-WDR)

• True Mechanical Day/Night function by ICR

• XD-DNR Noise Reduction

• IP67 Weather Resistance

• Supports Up The COAX Control

• Over 1500’ HD Video Transmission (Depending on cable characteristics and

integrity)

• 12VDC Operation

• Optional Wall Mounts (VT-TWMT-3, VT-TWMT-A1 [reqs. VT-TJB08]), Junction

Boxes (VT-TJB01, VT-TJB08), and Pendant Mounts (VT-TPDMT-A1 [reqs.

VT-TJB08], VT-TPDM-2 [reqs. VT-TJB01]) Available

[See Additional Mounting Options Below]

• 3 Year Warranty

ACCESSORIES

Image Sensor 1.29” 2.1 MegaPixel Progressive Scan CMOS Sensor

Signal System NTSC/PAL

Effective Pixels 1920 x 1080

Resolution HD-TVI / CVI / AHD: 1080p/720p (2.1 MegaPixel) / CVBS: 960H

Video Output HD-TVI / CVI / AHD & CVBS (Selectable)

Lens2.8mm - Fixed

Day/Night True Day/Night by ICR

Min. IIIumination Color: 0.005 [email protected], AGC ON / B/W: 0 lux

(with IR ON)

WDRDigital Wide Dynamic Range

IR LEDs 1 Matrix

IR Distance Up to 100’

Dynamic (Smart) IRYES

S/N Ratio≥52 dB (AGC Off)

Digital Noise Reduction 3D-DNR

Auto White BalanceYES (AWB)

BLCYES

Control over COAXYES (COC)

Transmission Distance Up to 1500’ (Depending on Cable Characteristics and Integrity)

Power Input 12VDC

Power Consumption IR Off: < 1W / IR On: < 3W

Weather ResistanceIP67

Operation Conditions-4°~122° / 10%~90% Humidity

Dimensions4.25 x 3.77” (108 x 95.7mm)

Weight16.58 oz. / 1.04 lbs. / 470g

4.25”

(108.0mm)

3.77”

(95.7mm)

VT-TJB08

Optional

Junction box

for Cable

Management

VT-TWMT-A1

Wall Mount -

reqs.

VT-TJB08

VT-TPDM2

Pendant

Mount - reqs.

VT-TJB01

VT-TPDMT-A1

10” Pendant

Mount -

reqs.

VT-TJB08

VT-TJB01

Optional

Junction box

for Cable

Management

VT-TPLMT

Universal

Pole Mount

Adapter -

reqs.

VT-TJB08+ VT-

TWMT-A1

VT-TCNMT

Universal Corner

Mount Adapter -

reqs.

VT-TJB08 + VT-

TWMT-A1

VT-TR4VPK

Video and Power

Balun Transmitter

/ Receiver Pair for

HD-TVI / AHD /

CVI for

Distances

Up to 1000’

VT-TR4K

Passive Video Balun

Transmitter / Receiver

Pair for HD-TVI / AHD

/ CVI for Distances Up

to 1440’

VT-TWMT3

Optional Wall

Mount

www.vitekcctv.com
