Vinten

Camera Control Solutions

Operators Guide

Vision 250

Pan & Tilt Head

Vision 250

Pan and Tilt Head

Publication Part No. 3525-8 Issue 3

or reproduced in any way including, but not limited to, photocopy, photograph, magnetic or other record without the prior

agreement and permission in writing of

Vinten Broadcast Limited.

Vinten, QuickFit and Vision are registered trademarks of Vinten Broadcast Limited.

Safety - read this first

Warning Symbols in this Operators Guide

Where there is a risk of personal injury, injury to others, or damage to the pan

and tilt head or associated equipment, comments appear, highlighted by the

word WARNING! and supported by the warning triangle symbol.

Technical data

Weight

Flat base (complete with pan bar) 6.05 kg (13.3 lb)

Ball base (complete with pan bar and bowl clamp) 6.39 kg (14 lb)

Height to mounting face

Flat base 184 mm (7.24 in.)

Ball base 171 mm (6.73 in.)

Length 159 mm (6.23 in.)

Width 244 mm (9.6 in.)

Typical payload 25 kg (55 lb) - See balance graph)

Tilt range ±90°

Pan range 360°

Pedestal/tripod fixing 100/150 mm ball

Four-hole flat base

Further information

For further information or advice regarding this pan and tilt head, please contact Vinten Broadcast

Limited, your local Vinten distributor or visit our website.

For full details on maintenance and spare parts, please refer to the Vision 250 Pan and Tilt Head

Maintenance Manual and Illustrated Parts List (Publication Part No. 3465-9), obtainable from Vint-

en Broadcast Limited or your local Vinten distributor. For information on-line, visit our website at

www.vinten.com.

Product specificaties

Merk:	Vinten
Categorie:	Statief
Model:	Vision 250
Kleur van het product:	Zwart
Gewicht:	16900 g
Hoogte (min):	683 mm
Hoogte (max):	1727 mm
Maximale gewichtscapaciteit:	33 kg
Materiaal:	Koolstofvezel
Bedoeld voor:	Digitaal/filmcamera
Opbergetui:	Ja
Draaihoek:	360 °
Lengte wanneer opgevouwen:	920 mm
Bereik kantelhoek:	-90 - 90 °
Aantal benen/poten:	3 poot/poten
Tripod hoofd:	Vision 250
