2.4G REMOTE CONTROL AIRCRAFT INSTRUCTIONS

Open the remote control on the back of the battery cover, the 3 grain 7 alkaline batteries (batteries

sold separately, and do not mix old and new or different types of batteries) in accordance with the

polarity of the battery box are loaded, then tighten the battery cover (Figure 1).

The function of the remote controller is shown in figure 2.

Power

indicator

Left

Throttle

trimming

Switch

High and

low speed

To turn to

Right

trimming

The assembly and function introduction of remote controller

Charging for aircraft batteries

Preparation before flight

Ready to take off

Yaw adjustment

Adjust the flight state of the aircraft by adjusting the fuselage

When the plane is flying in the air, if the aircraft rotates to the left, then light right fine tune (Figure 4)

until smooth; if the aircraft rotates to the right, then light left fine tune (Figure 5), until smooth.

1.Please choose no rain and snow, wind less than 4 outdoor environmental flight, avoid people,

animals and obstacles.

2.The original factory equipped with lithium batteries installed at the bottom of the aircraft battery

warehouse, and open the power switch, aircraft lights flashing, at this time will be placed on the

ground, waiting for the frequency.

3.Pull the throttle rod to the minimum, open the remote control power supply, push the throttle rod

from the lowest to the highest, then pull back to the minimum, the aircraft indicator lights become

normal, at this time to complete the code, you can fly.

1.Ground takeoff: choose a runway about 5-10 meters long, against the wind direction, push the

accelerator gradually to the maximum, the plane taxiing distance will take off automatically. If the

aircraft is taxiing on the ground, adjust the left and right trim of the remote control until the plane

is in a straight line.

2.Hand throwing off: use the second half of the fuselage to push the throttle, parallel to the direction

of the aircraft against the wind thrown into the air, not to tilt the aircraft (see Figure 3).

Figure 2

Figure 4

Figure 5

Figure 6

Figure 7

Figure 3

Battery cover

7 alkaline battery

Climb too fast

Unable to climb

Correct direction

(Against the wind)

PROBLEM

Propeller does not

rotate

Take off and turn

around or take off

soon after takeoff

Can't take off or fly

down

*Open power switch

*Lack of aircraft capacity

*Not adjusting the balance

*The plane did not take off from the wind

*Lack of aircraft capacity

*The angle of the aircraft is not enough or

the speed is not enough

*Turn on the power switch

*Charging aircraft

*Fine tuning and body adjustment

*Take off at takeoff

*Charging aircraft

*More skillful operation of the direction bar

Drop in ascent or

takeoff

*Lack of aircraft capacity*Charging aircraft

The airplane doesn't

respond to the

instructions of the

remote controller or

react slowly

*Interference by high voltage lines, other

remote control products or buildings

*As far as possible avoid this situation, choose

another place operation

Be out of control*Beyond the controlled range*Operate within the remote control range

(remote control 80 meters)

REASONRESOLVENT

Aircraft failure and repair

The flight state of the aircraft can be adjusted by bending the tail of the aircraft. When bending, it is

necessary to press the bending part with fingers to avoid breaking. When the plane is not easy to

take off, turn the tail up (see Fig. 6). When the plane climbs too fast, bend the tail of the aircraft

(Fig. 7).

Figure 1

Insert the original USB charging line into the

computer USB socket, then the indicator light

doesn't turn on, and then connect the power

The red indicator lights up, so that it can be

charged, and when the indicator goes out, it

means full.

The charge time is about 40 minutes.

®
