size: 14. 5x21cm (Wf)

Technical Support and E-Warranty Certificate

www. ve vo r. co m/s u p po rt

Woodworking Roller Stands

User Manual

MODEL: YH-WB004

We continue to be committed to provide you tools with competitive price.

"Save Half, "Half Price" or any other similar expressions used by us only

represents an estimate of savings you might benefit from buying certain tools

with us compared to the major top brands and does not necessarily mean to cover

all categories of tools offered by us. You are kindly reminded to verify carefully

when you are placing an order with us if you are actually Saving

Half in comparison with the top major brands.

Woodworking Roller Stands

MODEL: YH-WB004

(The picture is for reference only, please refer to the actual object)

NEED HELP? CONTACT US!

Have product questions? Need technical support? Please feel free to

contact us:

Technical Support and E-Warranty Certificate

www.vevor.com/support

This is the original instruction, please read all manual instructions

carefully before operating. VEVOR reserves a clear interpretation of our

user manual. The appearance of the product shall be subject to the

product you received. Please forgive us that we won't inform you again if

there are any technology or software updates on our product.

1

Dear Customers

Before use please familiarise yourself with the correct use and operation of the

work stand and retain these operating instructions for future reference.

These operating instructions contain important details for the handling and use of

the work stand.

Please read the safety instructions carefully and observe the correct method of

use for each function.

These instructions will make it easier for you to handle the work stand

appropriately and help prevent misuse, injury and possible damage.

Safety Notes

Please adhere to the following safety notes to avoid malfunctions,

damage or physical injury:

• Keep this manual with the work stand. It contains important notes on operating

the unit.

• Do not wear loose fitting clothing, neckties, rings, bracelets, or other jewellery

that can get caught in moving parts. Non-slip footwear is recommended.

Wear protective hair covering to contain long hair.

• Use the work stand only for its intended purpose. Do not use the work stand as

scaffold, ladder, stool or similar.

• Do not stand on the work stand.

• Keep bystanders and obstacles away from the work area.

• Use the work stand on solid level ground and make sure the ground will

support the weight of the work stand and the weight of the workpiece.

• Do not exceed the maximum load capacities contained in these instructions.

See technical data for details.

• When working with a heavy or large workpiece please consider getting

assistance from another person.

• Inspect the work stand prior to use. Do not use the work stand if any parts are

damaged or bent.

• Do not drop the work stand, throw it, or otherwise misuse the work stand.

• Dispose of the packaging materials carefully; the plastic bags may become a

deadly toy for children.

• Always wear suitable protection when working with the work

stand.

2

Technical Data

Work Stand Dimensions680x750x823/1277mm

Max. Load Capacity for Working Table200 kg

Max. Load Capacity for Rollers and Ball Bearings100 kg

Max. Load Capacity for V-Shaped Rollers45 kg

Components

Carefully examine the contents of the pack to ensure that you have all the

required components as shown in the list below.

I

8x

M6 37mm

J

8x

o

M6

K

8x

o

M6

L2x

1

M2x

G

N

O2x

o

M8

P

1x

M8 16mm

Q

1x

M8

The assembly of the product will require the use of the following tools:

10mm spanner and two 13mm spanners or an adjustable wrench.

Cross slot No.3 or an 8mm slotted screwdriver.

3

Assembly

4

Assembly

Please read through the instructions to familiarise yourself with the construction

of the product prior to beginning assembly.

Leg stand assembly

Fit plastic stabiliser feet part ‘N’ to the bottom of leg stands ‘E’ (Fig 1).

Bolt the leg support bars part ‘B’ to part ‘E’ using eight M6 x 37mm bolts and nuts

and eight washers - part no I,J & K as (Fig 2) to form assembly as (Fig 3).

Rotating head assembly

Insert the adjuster bars part D’ into the rotating head assembly part ‘A’ (Fig 4)

and fix in place using four M8 x 40mm bolts and nuts and eight washers - parts

F,G & H.

Pull back the locking bar R’ and rotate the head assembly so that the trestle head

fixing brackets are facing upwards as (Fig 5). The head may be fixed in one

position when required by using a locking bolt, nut and washer - parts

0,P & Q. See page 6 for further details.

Slot the trestle head assembly C’ over the fixing brackets (Fig 6) and fix in place

using four M8 x 40mm bolts and nuts and eight washers - parts F,G & H.

Final assembly

Slide the completed head assembly into the leg stand (Fig 7). Adjust to the

required height ensuring the adjuster bar and stand locking holes are aligned,

insert the holding clips part ‘M’ into position on both bars to hold the head in

position. Lock the entire assembly in place by screwing in the locking levers part

‘L’ in to the frame (Fig 8). Both sides must be set to the same level.

5

Assembly

V-Roller adjustment

Push down the spring mechanism to tilt the V-shaped Rollers.

Fixed head mounting

Locking Point Locking Bolt with Nut

For additional security the

head can fixed in one

position.

Use the locking bolt, washer

and nut - parts O,P & Q as

provided to lock head in one

position.

Disposal

Dear Customer,

Please help avoid waste materials.

If you at some point intend to dispose of this article, then please keep in mind

that many of its components consist of valuable materials, which can be

recycled.

Please do not dispose of with household waste, but check with your local

council for recycling facilities in your area.

6

Rotary Head

The four function head can be easily rotated to the suitable manoeuvring support for the

job and material being worked.

Stationary

Support:

for use as conventional

trestle.

Max. load capacity: 200kg

Roller

Support:

for use with bench saws.

Max. load capacity: 100kg

Ball Support:

for multi-directional

movement

(e.g. when milling).

Max. load capacity: 100kg

V-Support:

for centered guiding of

round material.

For this setting the trestle head

should be removed

Max. load capacity: 45kg

7
