Table of ContentsRev. 6/21/2019 WTJ-HITCH MANUAL

Table of ContentsCopyright 2019 Vestil Manufacturing Co.Page 1of 9

Hitch-Mounted Jib Crane Model WTJ-HITCH

Instruction Manual

Receiving instructions:

After delivery, remove the packaging from the product. Inspect the product closely to determine whether it

sustained damage during transport. If damage is discovered, record a complete description of it on the bill of

lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance comply

with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service Department (TSD) and Replacement Parts:

For answers to questions not addressed in these instructions and to order replacement parts, labels, and

accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be

contacted online at http://www.vestilmfg.com/parts_info.htm

.

Table of Contents

Specifications……………...………….…………………..………………………………………………………………………. 2

Signal Words….……………………..……………………………………………………………………………………………. 2

Hazards……………………………………………………………………………………..……………………………………… 3

Labeling Diagram……...………………………………………………………………………………………………………….. 3

Exploded View & Bill of Materials…………..…………………………………………………………………………………… 4

Assembling theCrane……………………………………………………………………………………………………....

5, 6, 7

Post Angle Adjustments……...……….………………………………………………………………………………................ 7

Using the Crane..……………………………………………………………………………………………………………….

7, 8

Record of Normal Condition……………………………………………………………………………………………….......... 8

Inspections & Maintenance………………………………………………………………………………………………………. 8

Limited Warranty…...……………………………………………………………………………………………………………... 9

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

Web: www.vestilmfg.come-mail: info@vestil.com
