Table of ContentsRev. 10/2/2020 LLW MANUAL

Table of ContentsCopyright 2020 Vestil Manufacturing Co. Page 1 of 21

LLW, LLPW, ALLW, & ALLPW Light Load Lifters

Use and Maintenance Manual

-A)LLWFW -(A)LLPWFW (A)LLW-4SFL - (A)LLPW4SFL

Receiving Instructions

A fter delivery,remove the packaging from the product. Inspect the product closely to determine whether it

sustained damage during transport. If damage is discovered, record a complete description of it on the bill of lading.

If the product is undamaged, discard the packaging.

NOTE:The enduser is solely responsible for confirming that product design, use, and maintenance comply with -

laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

Foranswers to questions not addressed in these instructions and to order replacement parts, labels, and

accessories, call our Technical Service and Parts Department at (260) 6657586. The Department can also be -

contacted online at http://www.vestilmfg.com/parts_info.htm

.

Electronic Copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-manuals.php

.

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 6657586 --or0868- Toll Free (800) 348-

Fax: (260) 665-1339

Web: www.vestilmfg.com e- mail: [email protected]om

Table of Contents

Page

Specifications (dimensions, capacity, net weight): LLW & ALLW……………………………………………….......

2

Specifications (dimensions, capacity, net weight): LLPW & ALLPW………………………………………….…….

3

Signal Words….…………………………………………………………………………………………………..……….

4

Safety Instructions..…….…………..………………………………………………………………..………..………….

4

LLW--202058FW Exploded View & Bill of Materials….…………….…………………………………....……........ ..

5

ALLW--2020FW Exploded View & Bill of Materials…………………..………….…………………….......…………

6

ALLW--2020FWFL Exploded View & Bill of Materials………………………………………………………………..

7

LLW--202058FWFL Exploded View & Bill of Materials………………………………………………………………

8

LLW--202058FWWL Exploded View & Bill of Materials………………………………………………………………

9

LLW--2420604SFL Exploded View & Bill of Materials………………………………...…….………………….…….

10

ALLW--24204SFL Exploded View & Bill of Materials……………………………………........................................

11

LLPW500--FW Exploded View & Bill of Materials……………………………………….....…………………….......

12

LLPW500--FWFL Exploded View & Bill of Materials………………………………………………………………….

13

ALLPW--500FW Exploded View & Bill of Materials………………………………………………………….………..

14

ALLPW--500FWFL Exploded View & Bill of Materials………………………………………………………………..

15

LLPW500--4SFL Exploded View & Bill of Materials…………………………………….…………………....……….

16

ALLPW--5004SFL Exploded View & Bill of Materials………………………………………………………….……..

17

Raising and Lowering the Deck….……………………………………………………………………………………...

18

Using the Hand Truck..…..………………………………………………………………………………………………

1819-

Record of Satisfactory Condition………………………………………………………………………………….…….

19

Inspections & Maintenance…………………………………………………………………………….........................

20

Labeling Diagram……………………………………………………………………………………………………...….

20

Limited Warranty…...……………………………………………………………………………………………………..

21
