TABLE OF CONTENTSRev. 11/3/2021FPG, MANUAL

TABLE OF CONTENTSCopyright 2021 Vestil Manufacturing Co. Page 1 of 11

FPG SERIES PORTABLE GANTRY CRANES

Receiving Instructions

After delivery,remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, record a complete description of it

on the bill of lading. If the product is undamaged, discard the packaging.

NOTE:

The end-user is solely responsible for confirming that product design, use, and maintenance comply

with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels, and

accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can also

be contacted online at https://www.vestil.com/page-parts-request.php

.

Electronic Copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from

https://www.vestil.com/page-

manuals.php

Table of Contents

Page

Specifications……….……………………………………………………...…………………………………………...

2

Signal Words……………………………………………………………………………………………………………..

2

Safety Instructions……………………………...………………………………..……………………………………..

3

National Standards…………………………………………………………………………………………………….

3

FIG. 1: FPG-3 Exploded Viewand Bills of Materials……….…..………….……………………..……………….

4

FIG. 2: FPG-6 Exploded View and Bill of Materials……………………………………………………………….

4

FIG. 3: FPG-10 Exploded View andBill of Materials……………………………………………………………...

5

FIG. 4: FPG-20 Exploded View and Bill of Materials……………………………………………………………...

5

Assembling the Crane.………………………………………………………………………………………………..

6 - 7

Using the Crane………………………………………………………………………………………………..……….

8

Recordof Satisfactory Condition………………………………………….………………………………………..

9

Inspectionsand Maintenance……………………………………………………………………………………....

9

Labeling Diagram………………………………………………………..………………………………………….…

10

Limited Warranty…………………………………………………………………………………….…………………

11

VESTIL MANUFACTURING CORP.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail:

HU[email protected]U
