Pagina 1/2

Package

Please make sure the following contents are in the HT380 gift box.

If something is missing or damaged, please contact your unitech representative.

The standard package contents

 HT380 Terminal With Hand Strap

 Battery

 Power Adapter For Cradle

 USB Type C Cable

 Cradle

 Quick Start Guide

The small package contents

 HT380 Terminal With Hand Strap

 Battery

 USB Type C Cable

 Quick Start Guide

Optional accessories

 Power Cord

- HT380 -

Quick Start Guide

608349G V1.3

Product View ( Left Right View ) /

Product View ( Front / Rear View )

Scanner trigger keys

USB / charge

connector

Rugged Handheld Terminal

System LED

indicator

Scan LED indicator

Touch screen

Key pads

Battery cover

lock

Speaker

Barcode scanner window

Flash LED

Autofocus

camera

Hand strap holes

Pogo pin for charging

NFC

lock

unlock

Remove / Install the Battery Cover

Move the battery lock to unlock icon to remove the

battery cover.

Slide and position the battery pack, making sure the

battery contacts are aligned with the contacts in the

compartment.

Using the Memory Card

The HT380 has 1 x memory card slot inside the battery

compartment.

Insert the memory card into the corresponding slot and gently push

the card to the correct positio n.

CAUTION!





To ensure the unit working properly, please keep all connectors

away from the contaminants staying inside of them such as dust,

grease, mud, and water. The negligence may cause the unit with no

communication, short circuited, overheated and so on.





If the connector is damaged, please ensure the connector is being fully

repaired before using the unit to avoid causing short circuited.

http://www.ute.com/

Checking the LED status

LED

LED Light

Description

Scan LED

Red light blinks once

￭ Barcode scan fail

Green light blinks once

￭ Barcode scan good read

System L ED

Solid green light

￭ When the terminal is operating

Blue light

￭ Customizable option

Solid red light

￭ Battery charging

Solid green light

￭ Battery fully charged

Charging the Battery

If the battery has been discharged for several days, you

may need to charge for several minutes before powering it

on. Use only the cradle and the adapter that came with this

device to charge the battery.

For other product documentation, please scan the QR code below for

more information.

Memory card slot

Product specificaties

Merk:	Unitech
Categorie:	Niet gecategoriseerd
Model:	HT380
Kleur van het product:	Zwart
Ingebouwd display:	Ja
Gewicht:	282 g
Breedte:	64.5 mm
Diepte:	34 mm
Hoogte:	182.6 mm
Soort:	Draagbare streepjescodelezer
Internationale veiligheidscode (IP):	IP65
LED-indicatoren:	Ja
Capaciteit van de accu/batterij:	4500 mAh
Bluetooth:	Ja
Beeldscherm:	IPS
Beeldschermdiagonaal:	3.2 "
Resolutie:	320 x 240 Pixels
Touchscreen:	Ja
Frequentie van processor:	1400 MHz
Processorfamilie:	Qualcomm
Maximale capaciteit van de geheugenkaart:	128 GB
Wi-Fi-standaarden:	802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth-versie:	4.2
GPS:	Ja
GLONASS:	Ja
Resolutie camera achterzijde (numeriek):	8 MP
Inclusief besturingssysteem:	Android 9
Near Field Communication (NFC):	Ja
Connectiviteitstechnologie:	Draadloos
Type stroombron:	Batterij/Accu
Compatibele geheugenkaarten:	MicroSD (TransFlash)
Trilalarm:	Ja
BeiDou:	Ja
Galileo:	Ja
Accu/Batterij voltage:	3.85 V
Certificering:	CE, RED, FCC, NCC, VCCI
Luidsprekers:	Ja
Ingebouwde flitser:	Ja
Intern geheugen:	2 GB
Bluetooth Low Energy (BLE):	Ja
Intern geheugentype:	DDR3
Ingebouwde camera:	Ja
Type processor:	Ja
Temperatuur bij opslag:	-30 - 60 °C
Processorfabrikant:	Qualcomm
ROM-capaciteit:	16380 MB
Soort scanner:	2D
Toetsenbordindeling:	Numerieke
Telefoonfunctie:	Ja
RFID lezer:	Ja
Wifi:	Ja
Bedrijfstemperatuur (T-T):	-20 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Batterijtechnologie:	Lithium-Ion (Li-Ion)
Kernen aantal:	8
