Pagina 1/20
Outdoor 4-Port PoE
Passthrough Switch
Model: N-SW
Introduction
Thank you for purchasing the Ubiquiti Networks®
NanoSwitch
™
. This Quick Start Guide is designed to guide you
through installation and also includes warranty terms.
Package Contents
Outdoor 4-Port PoE
Passthrough Switch
Model: N-SW
NanoSwitch
Self-Tapping
Screw
Metal Straps
(Qty. 2)
Quick Start
Guide
Installation Requirements
Mounting accessories and drain wire are not included.
Pole-Mounting
• Drill with a 4.5 mm Drill Bit
• 7 mm Socket Wrench or Screwdriver
Wall-Mounting
• (2) Screws (≤ 5 mm Screw Head)
• (1) Drain Wire, Optional (≤ 16 AWG, ≤ 40 cm)
Cables
• Shielded Category 5 (or above) cabling with drain wire
should be used for all wired Ethernet connections and
should be grounded through the AC ground of the PoE.
We recommend that you protect your networks from
harmful outdoor environments and destructive ESD events
with industrial-grade, shielded Ethernet cable from Ubiquiti
Networks. For more details, visit
www.ubnt.com/toughcable
• Surge protection should be used for all outdoor installations.
We recommend that you use two Ethernet Surge Protectors,
model ETH-SP, one near the N-SW and the other at the entry
point to the building. The ETH-SP will absorb power surges
and safely discharge them into the ground.
To LAN
ETH-SP
ETH-SP
POE-24-30W-G-WH
N-SW
