23-08-313-933217 REV D

HC150 and HCINT150 Series Application Guidelines

Series AGSM7328, AGSM7892

SAVE THESE INSTRUCTIONS – This manual contains IMPORTANT SAFETY

INSTRUCTIONS that should be followed during installation and maintenance of the UPS and

batteries.

The HC15

0 and HCINT150 series of hospital cart power modules are designed to provide AC voltage output

power from either utility provided AC input voltage or from inverting DC power from a battery. The HC150SL,

HC150LVR, and HCINT150SL may be configured for either a Lithium Iron Phosphate (Li-Ion) battery or a sealed

lead acid (SLA) battery. The HCINT150L model works only with a Li-Ion battery. To ensure proper operation, the

following guidelines should be observed:

General:

1.

The power module can support continuous AC loads up to a maximum of 150VA or 150

W.

2.

The HC150SL and HC150LVR models require 60Hz utility input. The HCINT150SL and

HCINT150L models

automatically

select the last utility frequency encountered (50Hz or 60Hz) for invert mode operation.

3.

The appliance inlet dongle serves as a disconnect device and shall be easily accessible

.

4.

Alternately, the socket-outlet of the end-product shall be installed near the equipment and shall be easil

y

acce

ssible or disconnect device provided within the end produc

t.

5.

A Remote User Interface (RUI) module must be connected to the power module using two CAT-5 cables

.

The COMM1

jacks should be connected together and the COMM2 jacks should be connected

together. If the

cabl

es are not connected or if they are interchanged, the power module will not operate. The

RUI may be

either a T

ripp Lite RUI or a customer designed RUI that meets Tripp Lite specifications.

6.

The power module is able to provide many operational parameters to monitoring software (such as Tri

pp

Lite’s PowerA

lert) running on a computer that has a USB connection to the power modul

e.

7.

The rated temperature range for the fan inlet air to the power module is 0°C to 40°C.

8.

The power module has internal over temperature protection. If the internal temperature becomes grea

ter than

85°C, the power m

odule will shut down (no VAC output and no charging). If the

temperature drops below

85°C, charging will resume but the VAC output will remain off until the On switch on the RUI is pressed.

9.

Whe

n using a Li-Ion battery, a communication cable is required from the power module COMM3 connec

tor to

the battery

communication connector. This allows the battery to communicate its operating parameters

to the

power modul

e, including state of charge and over temperature conditions (the power module

will interrupt

current into or out of a battery if a battery reports an internal temperature alarm exceeding about 60°C).

Cautio

n:To prevent possible damage to the power module, make battery DC power connections be

fore

makin

g communication connections (and reverse the procedure when disconnecting the ba

ttery).

10.

When using SLA batteries with HC150SL, HC150LVR, or HCINT150SL models, a communication cable is

not

use

d. To provide added fault protection for SLA batteries, the HC150SL and HCINT150SL models may be

equipped with optional temperature sensors (Tripp Lite P/N AC8441) connected from their THERM1 and

/or

THERM

2 connectors to the negative terminals of the batteries. The sensors need to be enabl

ed by

rep

rogramming the power module using a software tool available from Tripp Lite. The sensor

s allow the

power module to interrupt current into or out of a battery if a battery temperature exceeds 50°C. If a sensor

has been enabled, a missing or open sensor

will also cause a shut down.

11.C

AUTION: Double Pole/Neutral Fusing

.

1000 Eaton Boul

evard

Cleveland, OH 44122

United States

TrippLite.Eaton.com

Tripp Lite is now part of Eaton.
