Trendnet TEG-082WS Handleiding

Trendnet Schakelaar TEG-082WS

Bekijk gratis de handleiding van Trendnet TEG-082WS (138 pagina’s), behorend tot de categorie Schakelaar. Deze gids werd als nuttig beoordeeld door 11 mensen en kreeg gemiddeld 4.9 sterren uit 6 reviews. Heb je een vraag over Trendnet TEG-082WS of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/138

TRENDnet User’s Guide

Cover Page



© Copyright 2018 TRENDnet. All Rights Reserved.


TRENDnet User’s Guide
Table of Contents
a
Thank you for purchasing your new TRENDnet Web
Smart Switch!



Please note: The scope of this user's guide encompasses multiple
products with varying features. Images, artwork, and other specificities
including port count, interfaces etc. may not be identical to the model
you purchased. Please consult the specific model specifications for your
unit for a full list of supported features.



Please ensure your switch’s firmware version is V2.10.010 or newer for
Layer 2+ management features. See the Firmware Upgrade section in
this document for additional information regarding the firmware upgrade
procedure.



Contents
Web Smart Switch Series Product Overview .................................... 1
TEG-082WS Overview .................................................................................................... 1
Package Contents ................................................................................................ 1
TEG-082WS Hardware Features .......................................................................... 1
TEG-204WS Overview .................................................................................................... 3
Package Contents ................................................................................................ 3
TEG-204WS Hardware Features .......................................................................... 3
TEG-284WS Overview .................................................................................................... 5
Package Contents ................................................................................................ 5
TEG-284WS Hardware Features .......................................................................... 5
TEG-524WS Overview .................................................................................................... 7
Package Contents ................................................................................................ 7
TEG-524WS Hardware Features .......................................................................... 7
Switch Installation .......................................................................... 9
Desktop Hardware Installation ...................................................................................... 9
Rack Mount Hardware Installation ................................................................................ 9
Basic IP Configuration .................................................................................................. 10
Connect additional devices to your switch .................................................................. 13
Accessing switch management interfaces ...................................... 14
Access your switch management page........................................................................ 14
Dashboard ................................................................................................................... 14
View your switch status information ................................................................. 14
Switch View ................................................................................................................. 16
View your switch status information ................................................................. 16
Real-time Statistics ...................................................................................................... 16
View your switch status information ................................................................. 16
System .......................................................................................... 17

Product specificaties

Merk:	Trendnet
Categorie:	Schakelaar
Model:	TEG-082WS
Kleur van het product:	Zwart
Gewicht:	1500 g
Breedte:	280 mm
Diepte:	180 mm
Hoogte:	44 mm
LED-indicatoren:	Ja
Certificering:	CE, FCC
Netwerkstandaard:	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	802.1x RADIUS, HTTPS
Compatibele besturingssystemen:	Windows 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server
Web-gebaseerd management:	Ja
Rack-montage:	Ja
Mean time between failures (MTBF):	1054337 uur
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Power over Ethernet (PoE):	Nee
Switchingcapaciteit:	16 Gbit/s
MAC-adrestabel:	16000 entries
10G support:	Nee
Aantal VLANs:	256
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	8
Aantal Gigabit Ethernet (koper)-poorten:	8
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Throughput:	11.9 Mpps
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP-functies:	DHCP server, DHCP client
Beheerprotocollen:	HTTP/HTTPS (SSL v2/3 TLS), SNMP v1/v2c/v3
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 90 procent
MIB-ondersteuning:	MIB, MIB-II
Aantal Combo SFP-poorten:	2
Head-of-line (HOL) blocking:	Ja
