Gigabit Ethernet Media Converter

Note: It is recommended to use a TP-Link SFP module on TL-MC200, because other vendors’ modules may be incompatible.

LC-SC Fiber Cable

Package Contents: Media Converter, Power Adapter, User Guide

Scenario 1: Connect Devices with and without Optical Interfaces

Ethernet device

with optical interfaces

Media ConverterEthernet device

without optical interfaces

Gigabit Ethernet interface

Twisted-Pair Cable

Note:

1. Either two TL-MC101 converters or two TL-MC102 converters can work cooperatively. Two TL-MC200 converters with a pair of SFP module can work cooperatively.

2. One TL-MC200 can also cooperate with one TL-MC101 or one TL-MC102. However, the mode and wavelength of the SFP module used in TL-MC200 must be the same as the opposite end.

3. Connect the TX port of one converter to the RX port of the other using a ber cable.

Scenario 2: Connect Devices without Optical Interfaces

Twisted-Pair CableTwisted-Pair Cable

Ethernet device

without optical interfaces

Media ConverterMedia Converter

Ethernet device

without optical interfaces

Enlarge Your Ethernet Network

TL-MC101/TL-MC102/TL-MC200

Note: TL-MC102 is used as an example throughout this guide. Other models may dier in appearance.

For technical support and other information, please visit

https://www.tp-link.com/support/?type=smb, or simply scan the QR code.

Gigabit Ethernet interface

Gigabit Ethernet interface

1000BASE-X interface

Fiber Cable
