*Images may dier from actual products.
EasyCam C420 is used for demonstration in this guide.
Full-Color Turret Network Camera
Installation Guide
©2025 TP-Link 7100000192 REV1.0.1
2. Mount Camera
Option 2Option 1
Φ6 mm
Tilt: 0° to 75°
Pan: 0° to 360°
Rotate: 0° to 360°
Keep the protective lm during
installation and remove it before use.
Score of
camera base
Notch of
camera body
Score of
bottom case
Notch of
the shell
Φ6 mm
Φ3 mm
B
A
1
Φ3 mm
B
A
Φ25 mm
Box
1. Get Ready
2
3
Tilt: 0° to 75°
Pan: 0° to 360°
Rotate: 0° to 360°
44
3
2
1
Score of
camera base
Notch of
camera body
Score of
bottom case
Notch of
the shell
Keep the protective lm during
installation and remove it before use.
Lens
Built-in Microphone
RJ45 Network Interface
(supports PoE)
Integrated
Infrared-White LED
