Note:

If the bracket is not suitable for your computer, detach it from the

adapter's board and replace it with the low-prole bracket.

c.

Locate an available

PCIE

slot ( X1, X4, X8, or X16)

and carefully insert the adapter.

Note:

If the Bluetooth USB cable is not correctly connected to the

motherboard, the Bluetooth function won’t work even after driver

installation.

d. Locate an available F_USB connector and carefully

plug the Bluetooth USB cable into it.

1 Disable Bluetooth

a. Right-click My Computer, select Manage, go to

Device Manager.

b. Expand the Bluetooth node to nd your existing

Bluetooth device.

c. Right-click theexisting Bluetooth device and select

Disable.

Note: Make sure you have disabled all existing Bluetooth devices

(both built-in and the third party).

Device Manager

Bluetooth

Disable

Existing Bluetooth Adapter

f. Replace the case panel, plug in the power cable,

and turn on your computer.

To continue, ip the page over.

2 Connect to a Computer

a. Turn off your computer, unplug the power cable,

and then remove the case panel.

b. Connect the provided Bluetooth USB cable to the

adapter.

e. Connect the antenna(s) to the adapter.

Tip:

To maximize performance, make sure the path between the antenna and

your router is clear.

©2025 TP-Link 7100001760 REV1.0.1

Images may dier from your actual product.

WLAN Bluetooth

PCI Express Adapter

USB

USB

1. Ensure that your computer has an Intel motherboard, and

that your Router or Access Point supports the Wi-Fi 7

standard and uses WPA3 encryption.

2. Supported operating systems are Windows 11 and 10. To

use 6 GHZ, you need Windows 11 or later. For the MLO

feature, ensure you have Windows 11 version 24H2 or later.

3. If you plan on using Bluetooth and already have connected

Bluetooth devices, proceed with Step 1. Otherwise, skip to

Step 2.

Before You Start

Bluetooth USB Cable

Adapter
