Pagina 1/10
Washroom Di enser Servic nd Parts Manual sp e a
Tork Elevation M2 Centerfeed Towel Dispenser
559020A; 559028A
Revision Date: 3- - 12 18
1 of 10
Essity Internal
Tork Centerfeed H d Towel Dispenser:an
M2 Pro Centerfeed Syste m:
559020A Wh e; 559028A Black it
Dispenser Dimensions HxWxD Inches (cm):
14.4 x 9.4 x 9.0 (36.6 x 22.9 x 22.7 cm)
Cen rfeed Towel Product Optionte s:
100230 (Tork Premium, 1 ply DRC)
121201 (Tork Advanced, 2 ply)
121202 (Tork Advanced, 2 ply)
121204 (Tork Advanced, 2 ply)
120932 (Tork Advanced, 2 ply)
120133 (Tork Advanced, 1 ply)
Dispenser Parts
Part Description Replacement SKU
M2 ELEV HOOD (White)
225592P
M2 ELEV HOOD (Black)
225593P
200260 KEY FOR ALL
TORK DISPENSERS
200260 KEY
ELEVATION LOCK
(White)
2055 02
ELEVATION LOCK
(Black)
2055 03
TORX T20 WRENCH
225599F
ELEVATION M2 PRO
ASSEMBLY (Black)
225597P
ELEVATION M2 PRO
ASSEMBLY (White)
225596P
Part Description with Replacement Instructions
Parts with SKUs listed are available for orde as of the revision date on the manual. Contact an r
Essity Sales Rep or the Essity Quality Coordinator to o er these parts. rd
If no SKU is listed, the availability of the part is unknown. Please contact Essity Quality the
Coordinator for more information (see Contacting Essity section ).
Washroom Di enser Servic nd Parts Manual sp e a
Tork Elevation M2 Centerfeed Towel Dispenser
559020A; 559028A
Revision Date: 3- - 12 18
2 of 10
Essity Internal
Replacement SKU Description & Repla ment Instructionsce
225592P
225593P
M2 ELEVATION HOOD (White Black) or
The hood for the 559020A or 559028A can be removed without any tools. Open
the cover approximately 45 ees. It may be helpful to rest the cover againsdegr t
your chest. Push hinge pivot on cover out on one s e at a time, exing the plastic id
on the cover until the pin d n ges from the hole in the base of the unit. Then ise ga
change to other side, pushing pin out to the other side emoving it from the and r
hole. Insert pins on n cover into holes on base one side at a time. ew
Note: It may be easier to see the hinge pins for removal if the Pro unit is rst
removed from the base of the dispe e See instructions for Pro replacem ns r. ent.
225596P
225597P
M2 ASSEMBLY (White or Black)
Locate two tabs in the back inside of the dispenser, just above the towel tray. With
one hand, pinch the tabs together a at the same time, push the pieces to the nd,
right and left of the tabs down (this will free up the ribs holding the tray in place ).
At the same time, place other hand in the hole in the mouth/bottom of the
dispenser and pull the tray towards you. The tray will slide towards you, free of the
back of the di enser. To replace Pro assembly, slide tray underneath base of sp
dispenser, ensuring tab in bottom front of the tray slides over and the back ribs
click in place.
2055 02
2055 03
ELEVATION LOCK (White or Black)
The lock can be replaced by pressing the plastic tabs ach si to free the lock on e de
from the opening. A new lock can be snapped in plac e.
200260 KEY
200260 KEY FOR ALL TORK DISPENSERS
225599F
TORX T20 WRENCH
S Pro Adj tment s t n s tio ee “ us In truc io s ec n.
Mounting and Filling Instructions
Installation instruction eet and mounting template are provided inside each carton. sh
3 of 10
Washroom Dispenser Service Parts and
Manual
Tork Elevation Centerfeed Towel M2
Dispenser
559020A;
559028A
Revision Date:
3- -12 18
Essity Internal
loading
In
s
truction
s
3
.
-
1
.
2.
T
o
rk.
M2
xl
..
p
.
6
l
4
3.
A
/
B
A
B
"
_£
I
.
I
.
4.
2
.
c
2
.
C
lll
l
.
l
.
,
I'
J£_
5.
4
.
6
