MIXER/PREAMPLIFIER - MODEL 207t

Eurorack 200 series

Specifications:

Size: 28 HP - Depth: 28mm

Power: +12V 90mA / -12V 85mA

The Buchla 207t mixer six inputs two main outputs monitor output.has andas well as a

At the bottom right side of the mixer is a and gain pot The microphone input jack takes a microphone input with preamplifier.

1/4” TRS phone plug. Above it is the gain switch and knob which set the gain of the preamp. has two dierent The switch

ranges, and 55db 70db to cover most microphones that needs to be boosted to eurorack signal levels. The microphone input

can also be used for a signal from some other source such as an electric guitar or line level electric piano.

On the top right of the mixer, is one channel output jack, and one channel output jack, two mono "left” "right”MONITOR

outputs, and one stereo EXPANSION IN jacks. These last two jacks are actually a pair of inputs without attenuators, assign

control, or access to the MONITOR output. The jack on the left goes directly to the "left" output and the left right goes to the

"right" output. These inputs can be used to link the two mixers to form one 12 in, 2 out" mixer. To do this simply patch the SIGNAL

outputs of one mixer into the EXPANSION IN inputs of the other.

Horizontally on the bottom are the six mixer signal input jacks ('A" through "F").

Above these are s. Putting any of these switches in the up position sends the signal from that input six yellow MONITOR switche

to the MONITOR output on the mixer. The , when up, send the respective signal to the main SIGNAL outputs. six blue switches

The sliders are attenuators on the input signals going to the SIGNAL outputs. They have no eect on any signal going to the

MONITOR output.

Above the four centre sliders are which pan the signal between the "left" and "right" outputs. The input ASSIGNMENT pots

channels on either side of each mixer ("A" and "F") feature voltage controlled assign. Without any control voltage channel "A" is

assigned to the left output and channel "F" goes to the right output. As a control voltage increases the signal pans to the other

output channel. The two LED's below each control voltage input indicate which channel the signal is going to.
