Symmons Dia 353GB-24 Handleiding

Bekijk gratis de handleiding van Symmons Dia 353GB-24 (3 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 39 mensen en kreeg gemiddeld 4.4 sterren uit 7 reviews. Heb je een vraag over Symmons Dia 353GB-24 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Dia

®

Model NumbersSpecification

353GB-12 (18, 24, 36, 42)

ADA Grab Bar Series

Operation & Maintenance Manual

☐

353GB-1212" Grab Bar for ADA Applications

☐

353GB-1818" Grab Bar for ADA Applications

☐

353GB-2424" Grab Bar for ADA Applications

☐

353GB-3636" Grab Bar for ADA Applications

☐

353GB-4242" Grab Bar for ADA Applications

Dimensions

Measurements

A1-1/2", 38 mm

B

13-1/4", 337 mm (353GB-12)

19-1/4", 489 mm (353GB-18)

25-1/4", 641 mm (3h53GB-24)

37-1/4", 946 mm (353GB-36)

43-1/4", 1099 mm (353GB-42)

C

12", 305 mm (353GB-12)

18", 457 mm (353GB-18)

24", 610 mm (353GB-24)

36", 914 mm (353GB-36)

42", 1067 mm (353GB-42)

DØ 1-1/2", 38 mm

E(2x) Ø 3-1/16", 78 mm

F3-1/16", 78 mm

G1/2", 13 mm

Note: Dimensions subject to change without notice.

Finish Options

Limited Lifetime - to the original end purchaser in

consumer/residential installations.

5 Years - for industrial/commercial installations.

Refer to www.symmons.com/warranty for complete

warranty information.

Warranty

Note: Append appropriate -sufx to model number.

☐

-STNSatin Nickel finish

• Supports up to 250 lbs.

• 1-1/2" bar diameter

• 3" ange diameter

• Bar extends 1-1/2" from wall

• Concealed mounting for a clean look

• Meets WW-P-541/8B Federal Specication for

Manufacturing

• Meets ADA load requirements when properly installed

• Stainless steel construction

• Grab bar compatible with WingIts stainless steel grab

bar fasteners (p/n GBW40) for drywall applications

BB

DD

GG

FF

FINISHED WALLFINISHED WALL

AA

CC

EE

Product specificaties
