Pagina 1/6
Enforcer
™
Bullet
Security Camera
4K Ultra HD for DVRs
Instruction Manual
Security Made Smarter
EN
Introduction
Congratulations on the purchase of your Swann En-
forcer Bullet Security Camera.
• 4K Ultra HD video with sensor spotlight, siren
plus red & blue flashing lights
• Microphone to stream live & record audio
• True Detect™ Heat & Motion sensing for reli-
able alerts
• Powerful Night2Day™ color night vision
• Works in rain & snow all year round
• Reliable BNC cable connection
Important instructions
1. Make sure the camera is secured correctly and
stable if fastened in place.
2. Only use the supplied power adapter (12V) and
power splitter (if included).
3. Do not operate if wires and terminals are exposed.
Please note: Have a look at the camera location tips
included with your DVR to select the best location for
your camera. The camera location tips provided here
are for general purposes only.
Please read: All jurisdictions have specific laws and
regulations relating to the use of cameras. Before
using any camera for any purpose, it is the buyer’s
responsibility to be aware of all applicable laws and
regulations that prohibit or limit the use of cameras.
1
For instructions on how to configure your camera
for motion detection, changing image settings,
and other functions available, please consult the
manual for your DVR. Go to support.swann.com,
search for your model, then download.
Connecting the Camera2
1. Connect the video output and pow-
er input connections on the camera
to the corresponding connectors on
the supplied video & power cable.
2. Connect the supplied power split-
ter to the power input on the video &
power cable (repeat this step if mul-
tiple cameras are included).
3. Connect the supplied power
adapter to the other end of the pow-
er splitter then connect the power
adapter to a spare wall socket.
4. Connect the video output on the
video & power cable to an available
camera input on your DVR. Twist the
connection to lock it in place.
For single camera packs, connect the supplied power adapter
directly to the power input on the video & power cable.
2 3
Twist to lock
connectors
Video Input
Video & Power Cable
Connect this to your DVR
Power Splitter
connects here
Power Output
Power Adapter
connects here
Power Splitter
Power Adapter
Video & Power Cable
connects here
Connect to a spare
power outlet
4
1
3
2
8 7 6 5
4 1
VIDEO INPUTVIDEO INPUT
AUDIO
INPUT
AUDIO
INPUT
3 1
4 2
VGAVGA
LANLAN
12V12V
RS485RS485
AUDIO
OUTPUT
AUDIO
OUTPUT
Power Input
Video Output
