Pagina 1/24
Rev B Date: 10.02.2018
I:\Manuals\Reveal_Free Standing_Dry (Ambient)_Service_Cases 20-88461.pub
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
SCC P/N
20-88461
INSTALLATION
& OPERATING
MANUAL
REVEAL® FREE STANDING, DRY (AMBIENT) SERVICE MERCHANDISERS
> REAR SLIDING DOORS
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
> SEE PAGE 8 and 9 FOR FRONT PANEL, SIDE CLADDING, REAR PANEL & TOE-KICK
ATTACHMENT GUIDE
Models Are Shipped WITHOUT Panels or
Cladding Attached. See Pages 8 and 9 For
Component Attachment Instructions.
Model NR4847DSV Free Standing Unit
Shown After Front/Side Cladding and
Toe-Kick Have Been Attached
Model NR4847DSV Shown Before
Front/Side Cladding and Toe-Kick
Have Been Attached
Reveal
®
READ AND SAVE THESE INSTRUCTIONS
2
TABLE OF CONTENTS
TABLE OF CONTENTS …………………………………………………………………………………...…...
OVERVIEW / COMPLIANCE / LAMP REPLACEMENT PRECAUTIONS / WARNING / WIRING
DIAGRAM ………………………………………………………………………………..……………...
REVEAL® FREE STANDING DRY (AMBIENT) SERVICE MODEL APPLICABILITY &
DIMENSIONS ……………………………………………………………………………………….....
INSTALLATION: TOE-KICK & REAR PANEL REMOVAL / REMOVING CASE FROM PALLET ..….
INSTALLATION, CONT’D.: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL
FROM PALLET ..……………………………………………………………………………………….
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS …………………………………..
INSTALLATION, CONT’D: ATTACHING COMPONENTS / HANDLES ...……………………………….
INSTALLATION, CONT’D: ATTACHING SIDE PANELS, REAR UPPER AND LOWER PANEL ..….
INSTALLATION, CONT’D: FIELD WIRE (OR PLUG IN) CASE / TURN ON LED LIGHTS …………...
INSTALLATION, CONT’D: BUBBLE-WRAPPED GLASS (FOR SHELVING) ………………………….
CASE ADJOINMENT INSTRUCTIONS ………………………………………………………………….…..
CASE DESIGN: FRONT VIEW OF FREE STANDING, SERVICE MERCHANDISERS ...……………..
CASE DESIGN: REAR VIEW OF FREE STANDING, SERVICE MERCHANDISERS ..……………….
CASE DESIGN, CONT’D: POWER CORD & PLUG / LED LIGHT SWITCH LOCATIONS / LED
LIGHTS ………………………………………………………………………………………………….
CASE DESIGN, CONT’D: REAR SLIDING DOORS / DOOR OPERATION …………………………….
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ..…....…...…………...….
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) .………..………………......
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ……….
SERIAL LABEL INFORMATION & LOCATION ..…………………………….……...…....……………..…
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...…...…...….....
2
3
4
5
6
7
8
9
10
11
12-15
16
17
18
19
20
21
22
23
24
