Pagina 1/35
PN 54190
SELF-SERVICE REFRIGERATED BAKERY MERCHANDISER
READ AND SAVE THESE INSTRUCTIONS
Rev O Date: 10.27.2016 I:\Oper Manuals - PUB\Harmony\HMO(L)36R_4716_4716A_5936_54190.pub
INSTALLATION AND
OPERATING MANUAL
Models To Which This Manual Is Applicable*
HMO3936R, HMO3936R.7121, HMO4836R.5936 / HMO5136R.4716,
HMO5136R.7121, HMO7236R.4716A and HMO7536R
* Note: This Manual May Also Be Applicable To Models Not Listed Herein.
888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
HMO7536R
HMO3936R
HMO7536R (Shown With
Optional Security Grid)
HMO5136R.4716 (With Steps)
HMO4836R.5936 (With Ambient
Upper Glass Enclosure) /
Product Shown For Illustrative
Purposes Only
HMO5136R.7121 (Similar To
HMO3936R.7121) With Ambient
Upper Glass Enclosure & Acrylic Bins
2
TABLE OF CONTENTS
OVERVIEW AND WARNINGS ……..………………..…….………………………..…………………....…..
CASE REMOVAL FROM SKID (LEVELERS OR CASTERS) ……………………………………………...
INSTALLATION …………………………………………………………………..……...………………..…….
POSITIONING, ALIGNING, LEVELING UNIT, REMOVING FRONT GRILLE …..……………………….
START-UP AND OPERATION ……...….…………...…...…..………………………...………….……..……
MAINTENANCE FUNDAMENTALS - SHELF ASSEMBLY / LIGHT FIXTURES ..…………………..…...
MAINTENANCE FUNDAMENTALS - STEP ASS’Y / LED LIGHT FIXTURE & POWER SUPPLY
ACCESS …………....……………………………………………………………………………...…….
MAINTENANCE FUNDAMENTALS - REAR SLIDING GLASS DOORS / MAGNETIC CONDENSER
COIL FILTER……….…………………………………………………………………………………….
MAINTENANCE FUNDAMENTALS - UPPER SECTION WITH ACRYLIC BINS ………………..………
MAINTENANCE FUNDAMENTALS - HONEYCOMB AIR DIFFUSER …...……………………………….
OPTIONAL NIGHT AIR CURTAIN OPERATING INSTRUCTIONS ……...…………………..…………...
STANDARD NIGHT AIR CURTAIN LOCATION FOR MODEL HMO5136R.4716 ………….…………...
SECURITY GRID OPERATING INSTRUCTIONS (OPTIONAL) ………….………………..……………...
SERIAL LABEL INFORMATION & LOCATION …..………………………………………………………….
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) …………………….……...
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER) ………..
TROUBLESHOOTING: GENERAL OVERVIEW .…………..……………………………………….……….
TROUBLESHOOTING: CONDENSING SYSTEM (BY TRAINED SERVICE PROVIDERS ONLY) …...
TROUBLESHOOTING: EVAPORATOR SYSTEM (BY TRAINED SERVICE PROVIDERS ONLY) …...
TROUBLESHOOTING: CONDENSER PACKAGE OVERVIEW ………………..……..…….…………….
TROUBLESHOOTING: COMPRESSOR NOT ON / NO DISPLAY ON CONTROLLER ……..…...…….
TROUBLESHOOTING: LIGHTS NOT OPERATING ………………..…………...………………………....
CAREL® CONTROLLER - PROGRAMMING THE INSTRUMENT ……....……………………………….
CAREL® CONTROLLER - USER INTERFACE, SUMMARY TABLES OF ALARMS & SIGNALS …….
CAREL® CONTROLLER - Summary Table of Operating Parameters (After Programming Key) ……...
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ……...…….….....
3-4
5
6-10
11
12
13
14
15
16
17
18
19
20-21
22
23-24
25
26
27
28
29
30
31
32
33
34
35
