Pagina 1/104
OPERATION AND INSTALLATION
UTILISATION ET INSTALLATION
BEDIENING EN INSTALLATIE
OBSLUHA A INSTALACE
OBSLUHA A INŠTALÁCIA
OBSŁUGA I INSTALACJA
KEZELÉS ÉS TELEPÍTÉS
COMANDĂ ȘI INSTALARE
Wall mounted convector heater | Convecteur mural | Wandconvector | stěnný
konvektor | Nástenný konvektor | Konwektor wiszący | Fali konvektor | Convector de
perete
» CWM 500 P
» CWM 750 P
» CWM 1000 P
» CWM 1500 P
» CWM 2000 P
» CWM 2500 P
» CWM 3000 P
» CWM 500 U
» CWM 750 U
» CWM 1000 U
» CWM 1500 U
» CWM 2000 U
» CWM 2500 U
» CWM 3000 U
2 | CWM P | CWM U www.stiebel-eltron.com
CONTENTS | SPECIAL INFORMATION
SPECIAL INFORMATION
- Keep children under the age of3 away from
the appliance if constant supervision cannot
be guaranteed.
- Children from the age of 3 to 7 may switch
the appliance on and off, provided they are
supervised or have been instructed in the safe
operation of the appliance and understand
any risks that may result. This is subject to the
appliance having been installed as described.
Children from the age of 3 to 7 must not plug
the power cable into its socket or regulate the
appliance.
- The appliance may be used by children aged8
and older and persons with reduced physical,
sensory or mental capabilities or a lack of ex-
perience and know-how, provided that they
are supervised or they have been instructed
on how to use the appliance safely and have
understood the potential risks.
- Children must never play with the appliance.
Children must never clean the appliance or
perform user maintenance unless they are
supervised.
- Parts of the appliance can get very hot and
may cause burns. Particular caution is ad-
vised when children or vulnerable persons are
present.
- In order to avoid overheating, do not cover
the heater.
- Never install the appliance directly below a
wall socket.
- In the case of a permanent connection, the
appliance must be able to be separated from
the power supply by an isolator that discon-
nects all poles with at least 3mm contact
separation.
SPECIAL INFORMATION
OPERATION
1. General information �����������������������������������������3
1.1 Safety instructions ����������������������������������������������� 3
1.2 Other symbols in this documentation ����������������������� 3
1.3 Information on the appliance ��������������������������������� 3
1.4 Units of measurement ������������������������������������������ 3
2. Safety ���������������������������������������������������������� 3
2.1 Intended use ������������������������������������������������������ 3
2.2 General safety instructions ������������������������������������ 4
2.3 Test symbols ������������������������������������������������������ 4
3. Appliance description ���������������������������������������4
4. Operation �����������������������������������������������������4
4.1 Programming unit ����������������������������������������������� 5
4.2 Switching the appliance on and off �������������������������� 5
4.3 Standby mode ���������������������������������������������������� 5
5. Settings �������������������������������������������������������6
5.1 Standard display ������������������������������������������������� 6
5.2 Standard menu ��������������������������������������������������� 6
5.3 Configuration menu ��������������������������������������������� 6
6. Cleaning, care and maintenance ���������������������������8
7. Troubleshooting ����������������������������������������������8
INSTALLATION
8. Safety ���������������������������������������������������������� 8
8.1 General safety instructions ������������������������������������ 8
8.2 Instructions, standards and regulations �������������������� 8
9. Appliance description ���������������������������������������9
9.1 Standard delivery ������������������������������������������������ 9
10. Installation ����������������������������������������������������9
10.1 Installation site ��������������������������������������������������� 9
10.2 Minimum clearances �������������������������������������������� 9
10.3 Installing the wall mounting bracket ������������������������ 9
10.4 Appliance installation ������������������������������������������ 10
10.5 Removing the appliance ��������������������������������������� 10
10.6 Electrical connection ������������������������������������������� 10
11. Commissioning ��������������������������������������������� 11
12. Troubleshooting �������������������������������������������� 11
13. Appliance handover ���������������������������������������� 11
14. Specification ������������������������������������������������ 12
14.1 Dimensions and connections ��������������������������������� 12
14.2 Energy consumption data ������������������������������������� 12
14.3 Data table �������������������������������������������������������� 13
GUARANTEE
ENVIRONMENT AND RECYCLING
