BIO-7504 & BIO-7505 BIO PROTECTOR

All specications and information shown were current as of publication and are subject to change without notice.

750405BIOIS APR2022

CLEANING INSTRUCTIONS

1. Rinse cover with water to remove abrasive dust and dirt.

2. Wash with soap or mild detergent using a soft cloth. (DO NOT SCRUB.)

3. Rinse once more, then dry with a soft cloth or chamois.

4. To remove grease or wet paint, rub gently with a cloth wetted thoroughly

with naphtha, then wash and rinse. (DO NOT USE RAZOR BLADES.)

INSTALLATION INSTRUCTIONS

1. Place the cover over the reader. Be sure the keypad and print reader are

accessible through the front opening in cover.

2. Mark and drill 7 holes 3/16 in. (4.7mm).

3. Complete assembly as shown.

WARNING: This product can expose you to chemicals including Dichloromethane, which is known

to the State of California to cause cancer, and Bisphenol A (BPA),

which is known to the State of California to cause birth defects or other reproductive harm.

For more information go to www.P65Warnings.ca.gov.

Three year warranty or a one year limited warranty (from date of purchase) on most products.

See website for details. Electronic warranty form at .www.sti-usa.com/wc14

75009A NEOPRENE GASKET

FRONT OPENING

19018 ANCHOR

(7) PROVIDED

19025 #8 x 2 in. SCREW

(7) PROVIDED

750097C COVER - CLEAR

750097S COVER - SMOKE

5.0 in.

(127mm)

GASKET

TOP VIEW

5.5 in.

(139mm)

FRONT VIEW

4.75 in.

(120mm)

8.75 in.

(222mm)

6.75 in.

(171mm)

USAEMEA
