Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (ST4300USB3)
PortFunction
1Power LED• is receiving power.Solid:Hub
2USB-A Ports (4)• Used to connect USB devices to the .Hub
PortFunction
3Power Port
• Used with the , to power the Power Adapter
Hub.
4USB-B Port (Host)
• Used to connect the to the Host Computer
Hub.
Requirements
For the latest requirements, please visit , www.startech.com/ST4300USB3www.startech.
com/ST4300USB3EU, www.startech.com/ST4300USB3GBor
4 Port Black SuperSpeed USB 3.0 Hub
1
Installation
1. Connect the included power adapter to the USB hub. The power LED should light
up solid. Supplying external power is optional, however to ensure each USB port is
fully powered, connecting external power is recommended.
2. Connect the USB cable from the USB hub (type B port) to the host computer system.
NOTE: If connected to a USB 2.0 host port, the hub will only operate at USB 2.0 speeds.
3. The operating system should detect the hub immediately and automatically install
it.
4. Once installation is complete, USB 1.x/2.0/3.0 devices should be able to be
connected to the hub and recognized.
Specications
Bus InterfaceUSB 3.0
Number of Ports4
Chipset IDVLI VL810
Connectors
• USB-A x 4
• USB-B x 1
• DC Power x 1
LEDsPower x 1
Maximum Data Transfer RateUSB 3.0L 5 Gbps
Enclosure MaterialPlastic
Power Adapter5VDC, 2000mA, type M plug
Operating Temperature0°C~55°C (32°F~131°F)
Storage Temperature-20°C~85°C (-4°F~185°F)
Humidity5%~95% RH
Dimensions152.0mm x 59.6mm x 23.5mm
Weight480g
2
3
4
Product specificaties
| Merk: | StarTech.com |
| Categorie: | USB Hub |
| Model: | ST4300USB3EU |
| Kleur van het product: | Zwart |
| Gewicht: | 55 g |
| Gewicht verpakking: | 440 g |
| Breedte verpakking: | 150 mm |
| Diepte verpakking: | 210 mm |
| Hoogte verpakking: | 80 mm |
| LED-indicatoren: | Stroom |
| Interface: | USB 3.2 Gen 1 (3.1 Gen 1) |
| Temperatuur bij opslag: | -20 - 60 °C |
| Compatibele besturingssystemen: | Windows XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ Server 2008 R2/ 7(32/64-bit), Mac OS 10.2 - 10.6 |
| Mac-compatibiliteit: | Ja |
| Output current: | 2 A |
| Spanning: | 5 V |
| Afmetingen (B x D x H): | 95 x 68 x 23 mm |
| Chipset: | VLI VL810 |
| Overdrachtssnelheid: | 5000 Mbit/s |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 85 procent |
| Code geharmoniseerd systeem (HS): | 84719000 |
| Aantal poorten: | 5 |
| Hub-interfaces: | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
