Pagina 1/2

Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 07/05/2013

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x400WATXPowerSupply

• 1xPowerCord(NA)

• 1xInstructionManual

Installation

NOTE: Computerscontainsensitiveelectroniccomponentsthat

areeasilydamagedbystaticelectricityandexcessiveshock.When

handlingthepowersupplyandothercomponents,ensureyouare

properlygroundedusingananti-staticmatorsimilardevice.Ifanti-

staticequipmentisnotavailable,groundyourselfbytouchingthe

exteriorofthecomputercaseoranotherlargemetalsurfacebefore

handlinganyperipherals.

1. Installationofapowersupplyrequiressomemechanicalskill

andrequiresthatyouopenyourcomputercasetodisconnect

andreconnectwires.Ifyouareunfamiliarwiththiskindofwork,

considerbringingyourcomputerandnewStarTech.compower

supplytoyourlocalcomputerstoreforhelp.

2. Checktheredswitchontherearofthepowersupply,nextto

thepowercordplug.Besureitissettothecorrectvoltagefor

yourcountry.InNorthAmerica,itshouldread“115”.InEurope

andAustraliaitshouldread“230”.Tochangetheswitch,use

ascrewdriverinthenotchoftheswitchandslideittothe

oppositeside.Ifyouareunsureofthevoltageusedinyour

country,contactyourelectricityproviderbeforeproceeding.

3. Ifyouarereplacinganoldpowersupplyinyourcomputer,

ensurethecomputerisshutdownanddisconnectthepower

cordfromthebackoftheoldsupply.

4. Openyourcomputercase.Inmostdesigns,thecaseisopened

byremovingtwoorthreescrewsattherearofthecaseandthen

slidingthecoveringpanelbackwarduntilitcomesfree.Ifyour

caseisatowerstyle,ensurethatyouremovethepanelthatwill

exposethetopofthecomputer’smotherboard.Thisisgenerally

theleft-sidepanel.Therearemanydierentcasedesigns,

however,soifyouareunsureofhowtoopenyourparticular

case,consulttheusermanualforyourcaseorcontactyourlocal

computerstoreforhelp.

5. Withthecomputercaseopen,reviewtheconnectorsbeingused

fromyouroldpowersupply.Ifyouarebuildinganewcomputer,

reviewtheconnectorsthatyouwillneedtouse.Checkthetype

ofconnectoronyourmotherboardanduseeitherthe24or20

pinATXpowerconnectoronthepowersupplyasappropriate.

6. Disconnecttheoldpowersupplyconnectionsfrominside

yourcomputer.Harddiskdrive,CDdriveandoppydisk

driveconnectorsdisconnectbypullingontheconnector.The

motherboardconnector(s)haveaclipthatmustbepressed

whilepullingontheconnectortoreleasethem.Arocking

motionwhilepullingwillaidingettingtheconnectorsloose.

Neverpullonthewiresofaconnectortounplugit.

7. Checkthatallthewiresfromyouroldpowersupplyarefree.

Removethefourscrewsontherearofyouroldpowersupplyto

freeitfromthecomputercase.Supportthepowersupplywith

onehandifitcouldfallwhileremovingthelastscrew.(Suchasin

atowerstylecase.)Removethepowersupplybyslidingitback

andthenoutthroughthesideofyourcase.

8. Installyournewpowersupplybypositioningitthroughthe

sideortopofyourcase(dependingonyourcasestyle)andthen

backontothepowersupplymounts.Checkthattheorientation

withthescrewholesinyourcaseiscorrect;allfourholesmust

bealigned.Supportthepowersupplywithonehandwhile

threadingamountingscrewthroughthebackofthecaseand

ATX2POW400HS

400 Watt 20/24-pin Silent ATX 2.01 Computer Power Supply

*actual product may vary from photos

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages (whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

intothepowersupply.Thescrewshouldthreadsmoothlyand

shouldnotrequireeort.Donotforceitoryoucoulddamage

themountingholes.Ifthescrewwon’tthreadsmoothly,remove

itandchecktoensurethemountingholesarecorrectlylined

up.Repeatfortheremainingthreescrews.Donotfullytighten

anyofthescrewsuntiltheyallhavebeenthreadedintotheir

mountingholes.(Note:ConsiderStartechpartSCREWTHUMB

screwsforeasierinstallation.)

9. Tieunusedwiresawayfromfansandothermovingparts.

10. Replacethecasecoverandsecureit.Youmaywishtonot

replacethescrewsuntilafteryouhavecheckedthatall

connectionsareworking.

11. Toggletherearpowerswitchonpowersupplytoo.(The“0”

symbolontheswitch.)Connectthepowercordtothepower

supplyandplugitintoagroundedpoweroutlet.(Thepower

supplyMUSTbeconnectedtoagroundedoutlet.)Togglethe

rearpowerswitchtoon.

12. Startyourcomputer.Youshouldhearitsfansanddevices

immediatelybegintorun.Ifyoudonot,toggletherearswitch

onthepowersupplytoo,disconnectthepowercord,openthe

caseandcheckthatallconnectorsarewellseatedandsecure.

13. Whenyouhaveconrmedallconnectionsareworking,replace

thescrewsinyourcase.

14. Powersuppliescontainelectricalandelectroniccomponents

andshouldbedisposedofproperly.Ifyouarereplacingapower

supply,pleasefollowyourcity’srulesforproperdisposalof

electricalequipment.

Specications

Dimensions 5.51x5.91x3.35in.(140x150x86mm)

Weight 4.2lb(1.9kg)

AC Input Voltage 115V(10A)or230V(5.5A),50/60Hz

(ManualSwitching)

DC Output +3.3V +5V +12V1 +12V2 -12V +5Vsb

30A 28A 14A 15A 1A 2.5A

Output Power

(max.) 400W

Fan 12cm,dualballbearing

Certications FCC,TUV,UL,CUL

Output

Connectors

1xATX12VP4Power(4pin;v2.x)Male

1xATXSplitPower(20+4pin;v2.x)Male

1xMolexFan(3pin;TX3)Female

1xPCIExpressPower(6pin;v1.x)Female

2xSP4(4pin;SmallDrivePower)Female

4xLP4(4pin;MolexLargeDrivePower)Female

4xSATAPower(15pin)Plug
