Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: August 27, 2024
Product ID
1P1FFCN-USB-SERIAL
1P3FFCNB-USB-SERIAL
1P6FFCN-USB-SERIAL
1P10FFCN-USB-SERIAL
ComponentFunction
1Serial Port DB9• Connect to a Serial Peripheral Device
2DB9 Screws
• Used to secure the to the Serial DB9 Port Serial
Peripheral Device
• The included can be installed for DB9 Nuts
compatibility with or Serial Peripheral DevicesCables
• 1P1FFCN-USB-SERIAL DB9 Nutscomes with the
pre-installed and the includedDB9 Screws
3LED Indicators
• Data Receive LED: Green Flashes to indicate activity
• Data Transmit LED: Yellow Flashesto indicate activity
• USB LED: BlueSolid to indicate driver has been
installed, and USB connection enumerated
4USB Type A Port
• Connect the to an available USB to Serial Adapter
USB-A Port
Package Contents
1P3FFCNB-USB-SERIAL
1P6FFCN-USB-SERIAL
1P10FFCN-USB-SERIAL
• USB to Serial Adapter x 1
• DB9 Nuts x 2
• Quick-Start Guide x 1
FTDI USB-A to RS232 DB9 Null Modem Serial Adapter Cable - M/F
Requirements
• USB Type-A Enabled Computer x 1
For the latest drivers/software, product information, technical specications, and
declarations of conformance, please visit:
www.StarTech.com/1P1FFCN-USB-SERIAL
www.StarTech.com/1P3FFCNB-USB-SERIAL
www.StarTech.com/1P6FFCN-USB-SERIAL
www.StarTech.com/1P10FFCN-USB-SERIAL
Pinout Diagram
Installation
Install the Driver and Adapter
Note: Drivers should install automatically in most supported operating systems. If
they do not, please complete the following steps:
1. Navigate to:
www.StarTech.com/1P1FFCN-USB-SERIAL
www.StarTech.com/1P3FFCNB-USB-SERIAL
www.StarTech.com/1P6FFCN-USB-SERIAL
www.StarTech.com/1P10FFCN-USB-SERIAL
2. Click the tab.Drivers/Downloads
3. Under , download the appropriate for your operating Driver(s)DriverPackage
system.
43
1
PinRS-232
1DCD
2TXD
3RXD
4DSR
5GND
6DTR
7CTS
8RTS
9RI
2
2
12345
6789
1P1FFC-USB-SERIAL
• USB to Serial Adapter x 1
• DB9 Screws x 2
• Quick-Start Guide x 1
