SPEAKMAN SE-4360
CART ASSEMBLY INSTALLATION INSTRUCTIONS
Note- Holds up to 500 lbs.
STEP 1 – INSERT THE WHEELS INTO THE BOTTOM
OF ALL FOUR (4) POSTS.
STEP 2 – FASTEN A PAIR OF SLIP SLEEVES
AROUND THE GROOVE AT THE BOTTOM OF
EACH OF THE FOUR (4) POSTS.
STEP 3 – SLIDE THE BOTTOM SHELF OVER THE
TOP OF ALL FOUR (4) POSTS UNTIL IT RESTS
MAKE SURE THE TWO (2) LOCKABLE WHEELS
ARE ON THE SAME SIDE OF THE SHELF. TIP: IF
NECESSARY, USE A RUBBER MALLET TO FURTHER
SECURE THE SHELF.
STEP 4
- DETERMINE THE HEIGHT AND SIDE
TO PLACE THE HANDLE BAR. FASTEN A PAIR
OF SLIP SLEEVES AROUND THE GROOVE
CHOSEN FOR THE HANDLE ON TWO (2) OF
THE FOUR (4) POSTS.
STEP 5 – SLIDE THE HANDLE BAR OVER THE
TWO (2) POSTS UNTIL IT RESTS SNUGLY ON
T
HE SLIP SLEEVES. TIP: IF NECESSARY, USE
A RUBBER MALLET TO FURTHER SECURE THE
HANDLE.
STEP 6 – FASTEN SLIP SLEEVES ALONG THE
TOP GROOVE OF EACH OF THE FOUR (4)
POSTS.
STEP 7 – USING TWO (2) 3/8” X 1” LONG
BOLTS, FOUR (4) FLAT WASHERS, TWO (2)
LOCK WASHERS, AND TWO (2) NUTS,
ATTACH THE CENTER CROSS SUPPORT TO THE TOP
SHELF. TIP: USE THE SIXTH TOP OPENING IN THE
FRONT/BACK RAILS OF THE TOP SHELF.
STEP 8 –
SLIDE THE TOP SHELF OVER THE
TOP OF THE FOUR (4) POSTS UNTIL IT RESTS
SNUGLY ON THE SLIP SLEEVES. TIP: IF
NECESSARY, USE A RUBBER MALLET TO
FURTHER SECURE THE HANDLE.
THE CART ASSEMBLY IS NOW COMPLETE. FOR MOUNTING THE EYEWASH
