INSTRUCTIONS FOR MODELS

92-S-5002-01

For additional assistance or service please contact:

SPEAKMAN

®

800-537-2107

customerser[email protected]

www.speakman.com

S-5002-E2

S-5002-E175

S-5002-E15

TOOLS AND SUPPLIES

IMPORTANT

SAFETY TIPS

Cover your drain to prevent loss of parts.

MAINTENANCE

WARRANTY

Warranty information can be found at:

www.speakman.com

Thread Seal

Tape

(included)

Adjustable

Wrench

Be sure to read instructions thoroughly before

beginning installation. Do not overtighten any

connections or damage may occur. This showerhead

has an operating range of 20-80 psi.

Periodic cleaning using a mild soap and warm water

will help keep your Showerhead's appearance in its

original condition.

For best results, dry immediately with a soft, clean

cloth. DO NOT USE harsh and/or abrasive cleaners.

To help restore the finish, occasionally apply a

non-abrasive wax to your showerhead body (follow

manufacturers’ instructions).

On CHROME PLATED SHOWER HEADS, a two (2)

part white vinegar, one (1) part water solution can be

used to break down excessive mineral deposits on the

sprays. Let the showerhead soak in the solution for

about ½ hour then rinse thoroughly. Brush off any

remaining mineral deposits if necessary.

DO NOT USE the vinegar/water treatment on any

finish other than Chrome.

To reduce mineral build-up, turn the handle to RAIN

position to let the water drain out after every use.

ROUGH IN DIMENSIONS

Specifications:

Inlet: 1/2” NPT FEMALE

Model:S-5002-E15

Max. Flow Rate:1.5 gpm (5.7 L/min)

Min. Flow Rate:1.3 gpm (4.9 L/min) @ 45psi

FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED

AT 4.9 L/MIN (1.3 GPM) OR LESS.

Model:S-5002-E2

Max. Flow Rate:2.0 gpm (7.6 L/min)

Min. Flow Rate:1.75 gpm (6.6 L/min) @ 45 psi

FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED

AT 6.6 L/MIN (1.75 GPM) OR LESS.

Model:S-5002-E175

Max. Flow Rate:1.75 gpm (6.6 L/min)

Min. Flow Rate:1.50 gpm (5.7 L/min) @ 45 psi

FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED

AT 5.7 L/MIN (1.50 GPM) OR LESS.

1

Apply Thread Seal Tape to the outlet side of

shower arm in a clockwise direction.

2

Thread Shower head onto shower arm by turning

it in a clockwise direction. Tighten with adjustable

wrench. Turn water supply on and check for leaks.

3

Rotate Spray Face to change Spray Settings.
