E:\SONY TV\SY23_APRB_EU_RG_121\5054415121\5054415121_01EN.fm master page: Cover

5-054-415-12(1)

Reference Guide

Guide de référence

Guía de referencia

Referentiegids

Referenzanleitung

Guia de referência

Guida di riferimento

Referensmaterial

Referencevejledning

Viiteopas

Referanseveiledning

Przewodnik

Οδηγός αναφοράς

Başvuru Kılavuzu

LCD Monitor

FW-75EZ20L / 65EZ20L / 55EZ20L / 50EZ20L / 43EZ20L

5-054-415-12(1)

FW-75EZ20L / 65EZ20L / 55EZ20L / 50EZ20L / 43EZ20L

B2B EU.book Page 1 Monday, December 18, 2023 3:37 PM

E:\SONY TV\SY23_APRB_EU_RG_121\5054415121\5054415121_01EN.fm master page: Left

FW-75EZ20L / 65EZ20L / 55EZ20L / 50EZ20L / 43EZ20L

5-054-415-12(1)

Table of Contents

IMPORTANT NOTICE . . . . . . . . . . . . . . . . 2

Safety Information . . . . . . . . . . . . . . . . . 2

Connection Diagram . . . . . . . . . . . . . .4

Remote Control and LCD Monitor. . . .6

Pro settings. . . . . . . . . . . . . . . . . . . . . .7

BRAVIA Signage Free . . . . . . . . . . . . . .8

Control functions . . . . . . . . . . . . . . . .10

RS-232C . . . . . . . . . . . . . . . . . . . . . . . . . 10

IP control . . . . . . . . . . . . . . . . . . . . . . . . 11

Installing the LCD Monitor to

the Wall. . . . . . . . . . . . . . . . . . . . . . . . 12

Troubleshooting. . . . . . . . . . . . . . . . . 13

Specifications . . . . . . . . . . . . . . . . . . .14

Setting menus are subject to change without notice.

Note

• Before operating the LCD Monitor, please read the “Safety

Information”.

• Read the supplied safety documentation for additional safety

information.

• Images and illustrations used in the Setup Guide and this

manual are for reference only and may differ from the actual

product.

Location of the identification label

Labels for the LCD Monitor Model No., Production Date (year/

month) and Power Supply rating are located on the rear of the

LCD Monitor or package.

Notice for Radio Equipment

Hereby, Sony Corporation declares that the radio equipment

types FW-75EZ20L, FW-65EZ20L, FW-55EZ20L, FW-50EZ20L,

FW-43EZ20L are in compliance with Directive 2014/53/EU. The full

text of the EU declaration of conformity is available at the

following internet address: https://compliance.sony.eu

Hereby, Sony Corporation declares that the radio equipment

types FW-75EZ20L, FW-65EZ20L, FW-55EZ20L, FW-50EZ20L,

FW-43EZ20L are in compliance with the UK relevant statutory

requirements. The full text of the declaration of conformity is

available at the following internet address:

https://compliance.sony.co.uk

For this radio equipment, the following restrictions on putting into

service or of requirements for authorization of use apply in AT, BE,

HR, CY, CZ, DK, EE, FI, FR, DE, EL, HU, IE, IT, LV, LT, LU, MT, NL, PL,

PT, SK, SI, ES, SE, UK, UK (NI), IS, LI, NO, CH, BG, RO, TR, AL, BA, MK,

MD, RS, ME, Kosovo :

5150 - 5350 MHz band is restricted to indoor operations only.

Installation/Set-up

Install and use the LCD Monitor in accordance with the

instructions below in order to avoid any risk of fire, electric shock

or damage and/or injuries.

Installation

• The LCD Monitor should be installed near an easily accessible

mains socket.

• Place the LCD Monitor on a stable, level surface to prevent it

from falling over and causing personal injury or property

damage.

• Install the LCD Monitor where it cannot be pulled, pushed, or

knocked over.

About Manuals

This LCD Monitor comes with the following

manuals. Please retain the manuals for future

reference.

Setup Guide

•LCD Monitor

installation and setup.

Reference Guide (this

manual) / Safety

Information

• Safety information, remote

control, troubleshooting, wall-mount

installation, specification, etc.

Help

Find more troubleshooting and

other useful information directly

from your LCD Monitor. Press HELP

on the remote control to display a

list of topics.

IMPORTANT - Read the End User Software Licence

Agreement before using your Sony product. Using your

product indicates your acceptance of the End User Software

Licence Agreement. The software licence agreement between

you and Sony is available online at Sony website (https://

www.sony.net/tv-software-licenses/) or on your product

screen. Go to [Settings] t [System] t [About] t [Legal

information] t [Notices and licences].

IMPORTANT NOTICE

Safety Information

B2B EU.book Page 2 Monday, December 18, 2023 3:37 PM

Product specificaties

Merk:	Sony
Categorie:	Monitor
Model:	FW-50EZ20L
Kleur van het product:	Zwart
Gewicht verpakking:	16000 g
Breedte verpakking:	1240 mm
Diepte verpakking:	141 mm
Hoogte verpakking:	782 mm
Beeldschermdiagonaal:	50 "
Resolutie:	3840 x 2160 Pixels
Touchscreen:	Nee
Oorspronkelijke beeldverhouding:	16:9
Interne opslagcapaciteit:	16 GB
Ondersteund audioformaat:	AAC, OGG, AC4
Ondersteunde videoformaten:	MPEG1, MPEG2-PS, WEBM
Inclusief besturingssysteem:	Android
USB-poort:	Ja
Ondersteuning voor plaatsing:	Binnen
Ethernet LAN:	Ja
Kijkhoek, horizontaal:	178 °
Kijkhoek, verticaal:	178 °
Typische contrastverhouding:	1200:1
Helderheid:	350 cd/m²
LED backlight:	Ja
Aantal HDMI-poorten:	3
Audio-ingang (L, R):	1
Composiet video-ingang:	1
DVI-poort:	Nee
Aantal Ethernet LAN (RJ-45)-poorten:	1
Ingebouwde luidsprekers:	Ja
Gemiddeld vermogen:	20 W
Aantal ingebouwde luidsprekers:	2
Stroomverbruik (in standby):	0.5 W
Aantal USB-aansluitingen:	2
RS-232C:	Ja
HDCP:	Ja
High Dynamic Range (HDR)-technologie:	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
HDR-ondersteuning:	Ja
HD type:	4K Ultra HD
Display technologie:	LED
Responstijd:	6 ms
VESA-montage:	Ja
Paneelmontage-interface:	200 x 200 mm
Model:	Horizontaal/Verticaal
Bedoeld voor:	Commercieel
Bedrijfsuren (uren/dagen):	16/7
Computersysteem:	Nee
Contrast ratio (dynamisch):	400000:1
Schermdiameter in centimeters:	126 cm
Energie-efficiëntieklasse (SDR):	G
Breedte apparaat (met standaard):	1126 mm
Diepte apparaat (met standaard):	286 mm
Hoogte apparaat (met standaard):	718 mm
Gewicht (met standaard):	12700 g
Motion interpolation technologie:	Motionflow XR
Soort paneel:	VA
LED backlight-type:	Direct-LED
Schermbreedte:	1126 mm
Display diepte:	70 mm
Display hoogte:	653 mm
Display gewicht:	12100 g
HDCP versie:	2.3
Productontwerp:	Digitale signage flatscreen
Wifi:	Ja
Stroomverbruik (typisch):	140 W
Waasniveau:	3 procent
Apple AirPlay ondersteuning:	Ja
