OWNER’S MANUAL
2
IT
SOMMARIO
1. Informazioni generali 2
1.1 Informazioni per l’utente 2
1.2 Garanzia e assistenza post vendita 3
2. Informazioni di sicurezza 3
2.1 Raccomandazioni per la scelta dell’amplicatore audio 4
3. Installazione 4
3.1 Contenuto dell’imballo 4
3.2 Segnare sulla parete l’area di taglio mediante il template in dotazione 5
3.3 Tagliare lungo il perimetro segnato 5
3.4 Collegare i cavi audio al diffusore 6
3.5 Inserire il diffusore nel foro praticato 6
3.6 Fissare il diffusore alla parete 7
3.7 Orientamento del logo (solo modelli PL-563 E PC-563P) 8
3.8 Applicare la griglia magnetica 9
4. Accessori opzionali 10
4.1 Griglia magnetica quadrata (solo per modelli In-Ceiling) 10
4.2 Kit di Pre-montaggio (nuova costruzione) 10
5. Rimozione del diffusore 11
6. Dati tecnici 46 / 47
7. Posizionamento dei diffusori 48
7.1 Congurazioni di sistema 48
1.INFORMAZIONI GENERALI
1.1 INFORMAZIONI PER L’UTENTE
Gentile Cliente,
Desideriamo ringraziarLa e complimentarci con Lei per aver scelto i diffusori Palladio Level 5 per il
suo impianto audio/audio-video.
Poiché è nostro preciso interesse che Lei ottenga il miglior risultato possibile nell’ascolto e che ciò
avvenga nella piena sicurezza, La invitiamo a leggere attentamente, prima dell’installazione, questo
manuale d’istruzioni.
Qualora dovessero sorgerLe dubbi o curiositĂ , Le consigliamo di rivolgersi al personale tecnico del
Suo punto vendita, al distributore ufciale Sonus faber del Paese in cui vive o prendere contatto
direttamente con Sonus faber scrivendo a customerservice@sonusfaber.com.
Inne Le suggeriamo vivamente di registrarsi on-line sul sito www.sonusfaber.com: in questo modo
verrĂ informato da Sonus faber di tutte le novitĂ , iniziative ed eventuali promozioni.
Buona Musica!
4
2.1 - RACCOMANDAZIONI PER LA SCELTA DELL’AMPLIFICATORE AUDIO
Il dato di potenza di uscita richiesto ad un amplicatore in condizioni di utilizzo medio, dipende dalle
caratteristiche del sistema di altoparlanti (impedenza nominale e sensibilitĂ ) e dalle condizioni di
ascolto (livello acustico medio e distanza del punto di ascolto). Nel caso di un diffusore acustico con
impedenza nominale di 4 ohm ed una sensibilitĂ di 92 dBSPL, si ha la seguente tabella
Programmi audio a fattori di cresta più elevati richiedono potenze di amplicazione ancora più
elevate. Come si può notare, quello che costa in termini di amplicazione non è tanto il mantenimento
del livello di ascolto raccomandato quanto la gestione dei brevissimi istanti nei quali il segnale
musicale presenta livelli straordinariamente elevati.
3. INSTALLAZIONE
3.1 – CONTENUTO DELL’IMBALLO
• Diffusore
• Griglia magnetica
• Template per il foro
• Copertura protettiva in plastica
Ogni accessorio opzionale acquistabile separatamente, è illustrato al Capitolo 4.
I materiali da imballaggio possono essere inquinanti.
Non smaltire questi materiali come riuti domestici ma consegnarli ad un centro
raccolta e riciclo dei riuti.
Non lasciare i materiali per l’imballaggio alla portata dei bambini!
PossibilitĂ di avvelenamento o soffocamento a causa di ingestione.
DISTANZA DI ASCOLTO
POTENZA DI USCITA
DELL’AMPLIFICATORE
(MINIMA, PER CANALE) *
POTENZA ASSORBITA
CORRISPONDENTE
(PER CANALE) *
2 m 40 Wrms 0,8 W
2,5 m 63 Wrms 1,3 W
3 m 90 Wrms 1,8 W
3,5 m 125 Wrms 2,3 W
* per un livello di ascolto medio alla distanza di ascolto pari a 82 dBSPL
Sistemi di altoparlanti per la riproduzione sonora domestica non devono essere
utilizzati per diffusione sonora a volume elevato e continuativo, come ad esempio
in discoteca o per rinforzo sonoro. In questo genere di applicazioni le potenze in
gioco sono incompatibili con il corretto funzionamento del sistema di altoparlanti e
possono portare a guasti irreversibili ed in taluni casi a principi di incendio.
IT
