Pagina 1/31

36 - PRECAUTIONS 91477B159/A

PRECAUTIONS 36

General safety instructions 36

Installation 40

Appliance purpose 41

This user manual 41

Manufacturer’s liability 41

Identification plate 41

Disposal 41

Information for European Control Bodies 42

Energy efficiency technical data 42

To save energy 42

Light sources 42

How to read the user manual 42

DESCRIPTION 43

General description 43

Hob 43

Control panel 44

Other parts 44

Accessories 44

USE 45

Preliminary operations 45

Using the accessories 45

Using the hob 46

Using the storage compartment (where present) 47

Using the oven 47

Digital programmer 48

Cooking advice 50

Cooking information table 51

Cooking information table (auxiliary oven) 52

CLEANING AND MAINTENANCE 52

Cleaning the appliance 52

Cleaning the hob 52

Knobs 53

Cleaning the door 53

Cleaning the oven cavity 55

Vapor Clean (on some models only) 56

Extraordinary maintenance 56

INSTALLATION 57

Gas connection 57

Gas types and Countries 61

Burner and nozzle characteristics tables 61

Positioning 62

Electrical connection 64

Instructions for the installer 66

We advise you to read this manual carefully, which contains all the instructions for maintaining the

appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com

PRECAUTIONS

General safety instructions

Risk of personal injury

• WARNING: During use the

appliance and its accessible

parts become very hot. Keep

children well away from the

appliance.

• Protect your hands by wearing

oven gloves when moving food

inside the oven.

• Never try to put out a fire or

flames with water: Turn off the

appliance and smother the

flames with a fire blanket or

other appropriate cover.

• This appliance may only be

used by children aged 8 years

and over, and by people of

reduced physical, sensory or

mental capacity, or lacking in

experience in the use of

electrical appliances, provided

that they are supervised or

have been given instructions on

the safe use of the appliance

and of the hazards associated

with it.

• Children must not play with the

appliance.

• Keep children under the age of

eight at a safe distance unless

PRECAUTIONS - 3791477B159/A

they are constantly supervised.

• Keep children under the age of

8 away from the appliance

when it is in use.

• Cleaning and maintenance

must not be carried out by

unsupervised children.

• Make sure that the flame-

spreader crowns are correctly

positioned in their housings with

their respective burner caps.

• Be aware of how rapidly the

cooking zones heat up. Do not

place empty pans on the heat.

Danger of overheating.

• The cooking process must

always kept under control. A

short cooking process must be

continuously monitored.

• Fats and oils can catch fire if

they overheat. Do not leave the

appliance unattended while

preparing foods containing oils

or fats. If fats or oils catch fire,

never put water on them. Place

the lid on the pan and turn off

the relevant cooking zone.

• Do not place metal objects,

such as dishes or cutlery, on the

surface of the hob during

cooking as they may overheat.

• WARNING: leaving food

unattended when cooking

using fat or oil can be

dangerous and can cause a

fire. DO NOT attempt to

extinguish a fire with water. Turn

off the appliance and smother

the flames, for example with a

lid or a blanket.

• The appliance becomes very

hot during use. Take care never

to touch the heating elements

inside the oven(s).

• Do not insert pointed metal

objects (cutlery or utensils) into

the slots in the appliance.

• Do not pour water directly onto

very hot trays.

• Keep the oven door closed

during cooking.

• If you need to move food or at

the end of cooking, open the

door 5 cm for a few seconds,

let the steam come out, then

open it fully.

• The surfaces inside the storage

compartment (where fitted)

may become very hot.

• Do not open the storage

compartment (where present)

when the oven is on and still

hot.

• The items inside the storage

compartment (where present)

could be very hot after the oven

has been used.

• Do not rest any weight or sit on

the open door of the

appliance.

• Switch off the appliance

immediately after use.

• Do not pull the cable to unplug

the appliance (if installed).

• DO NOT USE OR STORE

FLAMMABLE MATERIALS IN

THE STORAGE

COMPARTMENT (IF

Product specificaties

Merk:	Smeg
Categorie:	Fornuis
Model:	CX92GM
Soort bediening:	Buttons, Rotary
Vermogen grill:	2700 W
Kleur van het product:	Roestvrijstaal
Ingebouwd display:	Ja
Gewicht:	72600 g
Breedte:	900 mm
Diepte:	600 mm
Hoogte:	900 mm
Grill:	Ja
Energie-efficiëntieklasse:	A
Gewicht verpakking:	82400 g
Breedte verpakking:	960 mm
Diepte verpakking:	670 mm
Hoogte verpakking:	860 mm
Vermogen brander/kookzone 2:	1800 W
Vermogen brander/kookzone 3:	3500 W
Vermogen brander/kookzone 1:	3000 W
Aantal branders/kookzones:	5 zone(s)
Type kookplaat:	Gaskookplaat
Type brander/kookzone 1:	Groot
Type brander/kookzone 2:	Medium
Type brander/kookzone 3:	Groot
Totale binnen capaciteit (ovens):	107 l
Voedingsbron oven:	Electrisch
Aantal ovens:	2
Aantal gaspitten:	5 zone(s)
Controle positie:	Voorkant
Energieverbruik (conventioneel):	0.99 kWu
Energieverbruik (geforceerde convectie):	2.88 MJ
Totaal vermogen van de oven:	- W
Netto capaciteit oven:	72 l
Thermostaatbereik oven:	50 - 260 °C
Brutocapaciteit oven:	72 l
Aantal schappen:	1 schappen
Type brander/kookzone 4:	Medium
Vermogen brander/kookzone 4:	1800 W
Oven vermogen:	- W
Wokbrander:	Ja
Positie brander/kookzone 1:	Links voor
Positie brander/kookzone 2:	Links achter
Positie brander/kookzone 3:	Centraal
Positie brander/kookzone 4:	Rechts achter
Oven 2 netto capaciteit:	35 l
Oven 2 afmetingen:	Klein
Oven 2 voedingsbron:	Electrisch
Oven 2 grill:	Ja
Type product:	Vrijstaand fornuis
Type brander/kookzone 5:	Klein
Positie brander/kookzone 5:	Rechts voor
Vermogen brander/kookzone 5:	1000 W
Oven 2 aantal planken:	1 schappen
Oven 2 energie-efficiëntieklasse:	A
Oven 2 brutocapaciteit:	35 l
Oven 2 vermogen:	2000 W
Oven 2 thermostaatbereik:	50 - 245 °C
