Simplified MFG VW2 Handleiding
Bekijk gratis de handleiding van Simplified MFG VW2 (23 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 13 mensen en kreeg gemiddeld 3.9 sterren uit 7 reviews. Heb je een vraag over Simplified MFG VW2 of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/23
Simplified MFG W Baseline Road Ste 102-121 Mesa, AZ 85210 www.simplifiedmfg.com 833-HDMI-411 (436-4411)• 550 • • •
VW2 Quick Start Guide
• The VW2 is a 4x4 fast switch 4K 18Gbps YUV
4:4:4 @60Hz. video matrix switch
• In Video wall mode, any one of four inputs
can be shown in 4K across all four displays
• Compact size makes it easy to place behind
a video wall installation
• There are 10 different modes that will allow
different configurations and combinations
of sources and how they are displayed
STBSTB STBSTB
Source 1 Source 2
Source 3
Source 4
HDMI
HDMI
HDMI
HDMI
The VW2 is a fast switching
video matrix that will allow
any one of the four sources
to be displayed across all
four displays if arranged in a
2x2 video wall format. The
VW2 can also create 1x4
vertically or many other
combinations.
VW2
4K/UHD 4x4 Matrix with
Video Wall Processor
VER 11.
Thank purchasing you for the VW2
The Simplified Manufacturing VW2 is designed to provide years of reliable service. At
Simplified MFG, we want the experience with this device to be the best possible and are
committed to helping achieve that experience. Please keep this manual for future
reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is
highly recommended to protect and extend the life of your equipment. Cable and satellite
boxes can send surges through the HDMI port as will the Simplified MFG HDSURGE can
help prevent damage from these occurrences.
Table of Contents
1. Introduction. .......................................................................................................1
2. Features. ..............................................................................................................
1
3. Package Contents. ...............................................................................................
1
4. Specifications. .....................................................................................................2
5. Operation Functions. Controls and .....................................................................3
5.1. Front Panel. ................................................................................................. 3
5.2. Rear Panel. .................................................................................................. 3
6. IR Remote ............................................................................................................
4
7. IR Pin Definition. .................................................................................................
5
8. EDID Management. .............................................................................................5
9. Video wall. ...........................................................................................................
6
10. Web GUI User Guide..........................................................................................
7
11.
RS- 232 Control Command. ...............................................................................
13
12.
Application Example. ........................................................................................
19
13. Warranty Information……………………………………………………………………. .20
Information……………………………………………………………………….20 14. Contact
