04-1075A

Introduction

The DisplayPort 1.2 to 3-Port HDMI MST Splitter boosts

your productivity by allowing you to connect three HDMI

displays to your DisplayPort Multi-Stream Transport

(MST) enabled computer.

Key Features and Benefits

• Capable of multiple display modes for various

applications. Mirror mode, Extended mode with

individual content on each display, and panoramic

video wall mode which combines multiple monitors

into one large display

• Supports UHD video resolutions up to 3840x2160

(4Kx2K) and 7.1-ch surround audio

• Compatible with DisplayPort 1.2 graphics cards with

AMD Eyefinity or NVIDIA Surround technology

• Plug-n-play, hassle-free set up - no software or driver

installation needed

• Premium aluminum housing delivers efficient heat

dissipation for dependable performance and superior

electro-magnetic shielding for optimal viewing quality

DisplayPort 1.2 to 3-Port

HDMI MST Splitter

User Reference Guide

Specifications

Package Contents

•DisplayPort 1.2 to 3-Port HDMI MST Splitter

• Micro-USB power cable

• User Reference Guide

System Requirements

• PC with an available DisplayPort 1.2 connection

• Windows® 10 / 8.1 / 8 / 7 (32-/64-bit)

Chipset STDP4320

Compliance DisplayPort 1.2a

Output signal HDMI

Maximum resolution 3840x2160 @30Hz

Audio 7.1-ch surround audio

Display mode Mirror, Extended, and Panoramic video wall

mode

Connectors

Input: 1x 20-pin, DisplayPort, Male

Output: 3x 19-pin, HDMI , Female

Power: Micro-USB, Female

Housing material Aluminum

Built-in cable length 10.24" (overall)

Dimensions 4.13" (W) x 0.65" (H) x 2.60" (D)

Weight 0.28lbs

Layout

Figure 1: DisplayPort 1.2 to 3-Port HDMI MST Splitter

DisplayPort In

HDMI Output (x3)

•DisplayPort In: Connect to PC's DisplayPort

•HDMI Output (x3): Connect to HDMI displays with

HDMI cables (not included)

•Micro-USB power port* (no data transfer): Connect

to a USB port using the included Micro-USB power

cable

*Note: This connection is required to power the

adapter.

Micro-USB power port

Product specificaties

Merk:	SIIG
Categorie:	Splitter
Model:	CE-DP0C12-S1
Kleur van het product:	Zwart
Gewicht:	122.4 g
Snoerlengte:	0.2 m
Materiaal behuizing:	Aluminium
Maximum resolutie:	3840 x 2160 Pixels
Certificering:	FCC, CE, RoHS
Volledige HD:	Ja
Maximale refresh snelheid:	30 Hz
Ondersteunde grafische resoluties:	1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1440,2560 x 1600 (WQXGA),3840 x 2160
Temperatuur bij opslag:	-20 - 70 °C
Aansluiting(en):	DisplayPort 1.2, Micro USB
Afmetingen (B x D x H):	105.1 x 17 x 66 mm
Video uit:	3x HDMI
Aansluiting video:	HDMI
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 90 procent
Hoeveelheid Video ports:	3
