 Centres

mm

Hole

mm

Hole

mm max

G 1/2”

G 1/2”

G 1/2” to suit

dual check valve

Con-Serv DCCFF

Hose Length mm

COLD

IN

HOT

IN

Pendleton

AUSH.4193 - BRIDGE MIXER

AUSH.4173 - BRIDGE MIXER WITH SPRAY RINSE

Please Note: This model does not suit incoming water pressure

below 100kPa or higher than 500kPa. The spray rinse model

requires a minimum inlet pressure of 100kPa to successfully

divert the water flow from the main tap to the spray rinse. The

stop cocks provided with this tap contain gauze filters. Please

ensure your plumber is advised of the minimum and maximum

water pressure, and to install the stop cocks as failure to do so

voids the tap warranty.

Temperature Range

Min 1°C. Max 70°C

Working Pressure

Min 100kPa (14.5psi). Max 500kPa (72.5psi)

Flow Rates AUSH.4193

 Bar: L/min

 Bar: L/min

 Bar: L/min

AUSH.4173

 Bar: L/min

 Bar: L/min

 Bar: L/min

Ideal performance obtained with equal hot & cold pressures.
