Sharp E758 75" UHD 4K HDR Commercial Monito Handleiding

Sharp Monitor E758 75" UHD 4K HDR Commercial Monito

Bekijk gratis de handleiding van Sharp E758 75" UHD 4K HDR Commercial Monito (85 pagina’s), behorend tot de categorie Monitor. Deze gids werd als nuttig beoordeeld door 5 mensen en kreeg gemiddeld 5.0 sterren uit 3 reviews. Heb je een vraag over Sharp E758 75" UHD 4K HDR Commercial Monito of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Pagina 1/85
Users Manual
Large Format Display
MODEL:
E758
E868
Please nd your model name on the label on the rear side of the monitor.
Table of Contents
Important Information �����������������������������������������������������������2 Recommended Use & Maintenance ������������������������������������9
Chapter 1 Installation
Setup Overview ������������������������������������������������������������������11
Mounting (for Customer) ����������������������������������������������������14
Prevent Tipping ������������������������������������������������������������������14
Changing the Logo Ornament Position ������������������������������14
Mounting (for Trained Installers) ����������������������������������������15
Mounting Location �������������������������������������������������������������� 16
Orientation ��������������������������������������������������������������������������17
Ventilation Requirements ����������������������������������������������������19
Mounting on Ceilings ����������������������������������������������������������19
Attaching Mounting Accessories ���������������������������������������20
Installing and Removing the Optional Table Top Stand �����21
Chapter 2 Parts Names and Functions
Control Panel ����������������������������������������������������������������������23
Terminal Panel �������������������������������������������������������������������� 24
Wireless Remote Control ����������������������������������������������������26
Chapter 3 Connections
Wiring Diagram �������������������������������������������������������������������28
Headphones Connection ���������������������������������������������������28
Connecting to a Personal Computer ����������������������������������29
Connecting to a Media Device with HDMI �������������������������30
HDMI-CEC Command ��������������������������������������������������������31
Internal Video Sources �������������������������������������������������������32
Media Player �����������������������������������������������������������������������32
Connecting a USB Device ��������������������������������������������������32
Chapter 4 Basic Operation
Power On and Off Modes ��������������������������������������������������� 34
Power indicator status ��������������������������������������������������������34
Energy Mode ����������������������������������������������������������������������34
When [RS-232C] is selected for control, [Power supply] and
[Quick Start] are set to [Off] �����������������������������������������������34
When [LAN] is selected for control, [Power supply] and
[Quick Start] are set to [Off] �����������������������������������������������35
Operating Range for the Remote Control ���������������������������36
Showing the Information OSD ��������������������������������������������37
Switching Between Sound Modes ��������������������������������������37
Switching Between Picture Modes ������������������������������������� 37
Setting the Aspect Ratio ����������������������������������������������������� 38
OSD (On-Screen Display) Controls ������������������������������������ 39
Using the Media Player Menu ��������������������������������������������41
Chapter 5 Advanced Operation
Creating a Power Schedule ������������������������������������������������45
Using Picture Modes ����������������������������������������������������������46
Setting Security and Locking the Monitor Controls ������������47
Locking the Button Controls �����������������������������������������������48
Chapter 6 External Control
Controlling the Monitor via RS-232C ����������������������������������51
Controlling the Monitor via LAN ������������������������������������������52
HTTP Browser ���������������������������������������������������������������������53
Commands �������������������������������������������������������������������������57
