• For Passive Dynamic or Ribbon Microphones

• Provides 37dB of Gain • Low Self-Noise

• Expands Your Preamp, Audio Interface, Mixing Console’s

Headroom for Improved Audio Quality

• Connects Directly to Your Microphone

• Powered by Phantom Power; No External Power Supply

is Required

SES-GHOST MICROPHONE PREAMPLIFIER

The Sescom Ghost is a must have tool for all studio and live audio

professionals longing for the best performance from their passive

dynamic microphones. With a boost of up to 37dB of gain, the

Sescom Ghost will provide a much crisper and cleaner sound

while providing the headroom you need on your recordings or live

production. Because the Ghost runs off phantom power, there is

no need for an external power supply, just plug directly into your

dynamic or ribbon microphone and connect its output via an XLR

cable to your preamp, audio interface, mixing console, etc... and

you’ll be set to experience more headroom than ever before! With

its robust and compact design, the Sescom Ghost offers

consistently reliable performance without cluttering your studio or

stage floor with additional cable runs. 1 year warranty.

FEATURES

SES-GHOST CONNECTIVITY

CONNECTION DIAGRAM

The SES-GHOST requires 48V

phantom power to function.

SPECIFICATIONS

• Gain: 37dB

• Frequency Response: 20Hz – 20kHz

• Input Impedance: 45KΩ @ 1khz, -20dB Input

• Output Impedance: 5.4KΩ

• Noise: -89dbu A-Weighted

1. INPUT: use 3-pin XLR to connect SES-GHOST and passive

ribbon microphone or dynamic microphone.

2. OUTPUT: use 3-pin XLR to connect SES-GHOST and 48V

phantom power.
